Hot Sintered Continuous Rim Diamond Saw Blade

Product parameters
Name: Hot Sintered Continuous Rim Diamond Saw Blade
Model Number: BW-CCSB-01
Use Type: Wet use only
Diameter: From 105 to 300 mm
Segment Thickness: 1.4mm,1.8mm,2.0mm,2.2mm
Segment Height: 10mm
Segment shape: Continuous Rim Type
Industry: Diamond tools
Usage: For Ceramic
Process Method: Hot sintered
Machine: Manual Handling Cutting Machine
Cutting result: Flat surface and even size

Product Description


Diamond Saw Blade-for Ceramic, Porcelain & Tile Cutting



Hot Sintered, Continuous Rim Type



Diameter: 105-300mm, hot sintered, suitable for cutting various Ceramic & Porcelain with perfect performance.



Wet use only, Fast & Easy cutting, long life, very less or no chips, perfect performance.



The following are the normal Specifications we are selling:



Code No. Diameter Hole(mm) Segment
Thickness
Segment
Height
BW-CCSB-01-01 105mm(4") 20/22.23/25.4 1.4mm 10mm
BW-CCSB-01-02 115mm(4-1/2") 20/22.23/25.4 1.4mm 10mm
BW-CCSB-01-03 125mm(5") 20/22.23/25.4 1.4mm 10mm
BW-CCSB-01-04 150mm(6") 20/22.23/25.4 1.8mm 10mm
BW-CCSB-01-05 180mm(7") 20/22.23/25.4 1.8mm 10mm
BW-CCSB-01-06 200mm(8") 20/22.23/25.4 1.8mm 10mm
BW-CCSB-01-07 230mm(9") 20/22.23/25.4 2.0mm 10mm
BW-CCSB-01-08 250mm(10") 25.4/30/50/60 2.0mm 10mm
BW-CCSB-01-09 300mm(12") 25.4/30/50/60 2.2mm 10mm



The above specification is only for Reference, other or special specification can be ordered by customers.





Kindly Note:



When place order for saw blades please inform the following:

  Diameter (Inch or mm)

  Inner Hole Size (Inch or mm)

  Installation hole (If, need drawing)

  Silent or None Silent Saw Blade

  Segment No. (how many pcs segment per blade)

  Segment Size (L x W x H, if possible please inform Steel Core Thickness)

  Use of saw blade (For Granite, or marble, or limestone, or Sandstone. or other material)

  Quantity NO. (How many pcs, or how many sets segments)

  Machine Powder/RPM (If possible)

  Expected Shipping Date

  Special Requirements (If)

If only order segments please inform the following:

  Diameter (Inch or mm)

  Segment No. (how many pcs segment per blade)

  Segment Size (L x W x H, if better to inform the Steel Core Thickness)

  Use of saw blade (For Granite, marble, limestone, Sandstone. or other material)

  Quantity NO. (how many sets segments)

  Machine Powder/RPM, Feed Speed, Normal Cutting Depth (If possible)

  Expected Shipping Date

  Special Requirements (If)





Safety First !





Please use the following before operating the cutting:
