Products category

Full bullnose CNC router bit

Add / Delete to Basket

Product parameters

Name:	Full bullnose CNC router bit
Model Number:	BW-RB-M0302(V)
Diameter	50mm--125mm
Stone shape	V shape
Grit number	50#,100#,200#,400#,800#,1500#,3000#
Use	Wet use
Usage	Designed for marble,granite,counter
Machine	CNC machine
Series	0#,1#,2#,3#,4#,5#,6#7# or1#,2#,3#,4#,5#,6#,7#,8#

Product Description

Full bullnose CNC router bit

These diamond router bits for stone are used for CNC machine,automatic processing the granite,

marble,other stones and the counter.Their merits are high efficiency of production,exact figure.

Using sequence: from rough grit to fine, finally polishing.

The following are different shapes design ,

including : A, B, D, E, F, G, H, I, L, M, N, O, P, Q, S, T, U, V, WF, DD, DC

Full bullnose CNC router bit

The following are the normal specification of the diamond router bit:

Diameter	Stone shape	Spindle	Thickness	Grit No	Series
50-125mm	A,B,D,E,F,G, H,I,L,M,N,O, P,Q,S,T,U,V, WF,DD,DC	M8,M10,M14, 1/2G",5/8-11" 22mm,35mm	20mm,30mm, 40mm,50mm	50#,100#,200#, 400#,800#, 1500#,3000#	0#,1#,2#,3# ,4#,5#,6#7# or 1#,2#,3#,4# ,5#,6#,7#,8#

The above specifications is only for reference.

Other or special specification may be available as customers' demand.

It including different types, segmented type and continuous rim type.

When order CNC concrete router bit please Confirm.

Code No. of CNC concrete router bit ( BW-RB-M0302(E))
Type(?)

Size(?)

Grit(?)

Connection(?)

Quantity(?)(You can order single piece or more ,also can order sets.)
