CNC T shape diamond router bit set

Add / Delete to Basket

Product parameters

Name:	CNC T shape diamond router bit set
Model Number:	BW-RB-M0302-T
Diameter	50mm--125mm
Stone shape	T shape
Thickness	20mm--50mm
Grit number	50#,100#,200#,400#,800#,1500#,3000#
Use	Wet use
Usage	Designed for marble,granite,counter
Machine	CNCmachine
Series	0#,1#,2#,3#,4#,5#,6#7# or1#,2#,3#,4#,5#,6#,7#,8#

Product Description

CNC T shape diamond router bit set

These diamond router bits for stone are used for CNC machine,automatic processing the granite,

marble,other stones and the counter.Their merits are high efficiency of production,exact figure.

Using sequence: from rough grit to fine, finally polishing.

The following are different shapes design ,

including : A, B, D, E, F, G, H, I, L, M, N, O, P, Q, S, T, U, V, WF, DD, DC

CNC T shape diamond router bit set

The following are the normal specification of the diamond router bit:

Diameter	Stone shape	Spindle	Thickness	Grit No	Series
50-125mm	A,B,D,E,F,G, H,I,L,M,N,O, P,Q,S,T,U,V, WF,DD,DC	M8,M10,M14, 1/2G",5/8-11" 22mm,35mm	20mm,30mm, 40mm,50mm	50#,100#,200#, 400#,800#, 1500#,3000#	0#,1#,2#,3# ,4#,5#,6#7# or 1#,2#,3#,4# ,5#,6#,7#,8#

The above specifications is only for reference.

Other or special specification may be available as customers' demand.

It including different types, segmented type and continuous rim type.

When order CNC diamond router bit set please Confirm.

Code No. of CNC diamond router bit set ( BW-RB-M0302(T))
Type(?)

Size(?)

Grit(?)

Connection(?)

Thickness(?)

Quantity(?)(You can order single piece or more ,also can order sets.)
