| Product parameters |
| Name: | Turbo Segmented Rim Diamond Dry Cutters (Small Saw Blades) |
| Model Number: | BW-DC-04 |
| Diameter: | From 105mm to 230mm |
| Type: | Dry or Wet Use |
| Segment Height: | 8mm,10mm |
| Segment Thickness: | From 1.8mm to 2.6mm |
| Usage: | Cutting Granite, Marble, Sandstone, Limestone etc. |
| Machine: | Manual Handling Cutting Machine or Table Cutting Machine |
| Steel Blank Type: | Normal or Silent |
| Cutting result: | Flat surface and even size |
| Processing Method: | Hot Sintered |
| Industry: | Diamond tools |  |
Diamond Dry Cutters - Turbo Segmented Small Saw Blade
Turbo Segmented Rim Diamond Dry Cutters (Small Saw Blades), diameter from 4"(105mm) - 9"(230mm), for fast cutting kinds of hard, medium hard, soft stone, like Granite, Marble, Sandstone, Limestone etc., and other construction materials like Concrete, Asphalt, Ceramic, Porcelain, Bricks, etc.
This type dry cutter is usually for cutting hard hard stone, Concrete, Bricks, etc.
Hot Sintered, Dry or Wet Use!
The following are the normal Specifications we are selling:
|
Code No. |
Diameter |
Segment Thickness |
Segment Height |
Bore (mm) |
|
BW-DC-04-01 |
105mm(4") |
1.8 |
8/10mm |
15.88mm(5/8") 20.00mm 22.23mm(7/8") 25.40mm(1") |
|
BW--DC-04-02 |
115mm(4.5") |
1.8 |
8/10mm |
|
|
BW--DC-04-03 |
125mm(5") |
2.0 |
8/10mm |
|
|
BW--DC-04-04 |
150mm(6") |
2.2 |
8/10mm |
|
|
BW-DC-04-05 |
180mm(7") |
2.2 |
8/10mm |
|
|
BW-DC-04-06 |
200mm(8") |
2.4 |
8/10mm |
|
|
BW-DC-04-07 |
230mm(9") |
2.6 |
8/10mm |
|
|
|
||||
The above specifications & photo is only for Reference, other or special specifications may be available as per customer's demand.
Kindly Noted ：
Safety First !
Before mounting the saw blade ensure that the machine cannot start (pull out main plug).
Rotational direction arrow of the saw blade has to match the spindle rotational direction.
Not suitable for grinding – grinding can lead to serious injury through segment break outs.
Saw specification has to be appropriate for the material to be cut.
Do not tilt the saw blade in the cut.
Do not carry out any curved cuts.
Allow cooling down breaks, if saw blade is sparking heavily (use reciprocating cut).
Use protective clothing.
Please use the following before operating the cutting:
