| Product parameters |
| Name: | Normal Segmented Diamond Saw Blades for Slab Edge Cutting of Grante |
| Model Number: | BW-SBG-01 |
| Type | Wet Use |
| Segment Height | 10mm,12mm ,15mm,20mm |
| Diameter | 250mm to 800mm |
| Usage | Cutting Granite,Sandstone,Kinds of Hard Stones with quartz |
| Advatage | Good sharpness and Long lifespan |
| Performance | Hightly stable |
| Machine | Bridge Cutting Machine,Manual Handling Cutting Machine |
| Steel Blank Type | Normal or Silent |
| Cutting result | Flat surface and even size |
| Processing Method | Silver Welded |
| Industry | Diamond tools |  |
Diamond Saw Blades for Granite Cutting - Normal Segmented
Normal Segmented Diamond Saw Blades for Slab Edge Cutting of Granite, Sandstone, kinds of Hard Stones with quartz, Suitable for Bridge Cutting Machine, Manual Handling Cutting Machine or Table Cutting Machine.
The following are the normal Specifications we are selling:
|
Code No. |
Diameter (mm/Inch) |
Hole (mm) |
Segment Height (mm) |
Segment No. (pcs/set) |
Steel Blank Type | Welding Method |
|
BW-SBG-01-01 |
250mm(10") |
50/60 | 10/12/15 |
18 |
Normal & Silent |
Silver Welded |
|
BW-SBG-01-02 |
300mm(12") |
50/60 | 10/12/15 |
21 |
||
|
BW-SBG-01-03 |
350mm(14") |
50/60 | 10/12/15/20 |
24/25 |
||
|
BW-SBG-01-04 |
400mm(16") |
50/60 | 10/12/15/20 |
28 |
||
|
BW-SBG-01-05 |
450mm(18") | 50/60 | 10/12/15/20 |
32 |
||
|
BW-SBG-01-06 |
500mm(20") |
50/60 | 10/12/15/20 |
36 |
||
|
BW-SBG-01-07 |
550mm(22") |
50/60 | 10/12/15/20 |
38 |
||
|
BW-SBG-01-08 |
600mm(24") |
50/60 | 10/12/15/20 |
42 |
||
|
BW-SBG-01-09 |
700mm(28") |
50/60 | 10/12/15/20 |
50 |
||
|
BW-SBG-01-10 |
750mm(30") |
50/60 | 10/12/15/20 |
50 |
||
|
BW-SBG-01-11 |
800mm(32") |
50/60 | 10/12/15/20 |
46 |
||
 |
||||||
wet use only, Fast & Easy cutting, long life, very less or no chips, perfect performance.
The above specification is only for Reference, other or special specification can be ordered by customers.
Noted:
Warning: Please use high frequency Silver Welded machine to make the brazing if you only order diamond segments, and not to use Fire to braze the segment to the saw blank, otherwise the diamond will be damaged then the cutting performance will be influenced(Reduced)!
