Your position: Home > Products > Stone Tools > Stone Cutting Tools > Granite slab cutting saw blades > Diamond Saw Blades with Diagonal Groove Turbo Segments for Slab Edge Cutting of Granite
| Product parameters |
| Name: | Diamond Saw Blades with Diagonal Groove Turbo Segments for Slab Edge Cutting of Granite |
| Model Number: | BW-SBG-03 |
| Type | Wet use only |
| Segment Height | 10mm,12mm |
| Diameter | 250mm to 600mm |
| Usage | Cutting Granite,Sandstone,Kinds of Hard Stones with quartz |
| Advatage | Good sharpness and Long lifespan |
| Performance | Hightly stable |
| Machine | Bridge Cutting Machine,Manual Handling Cutting Machine |
| Steel Blank Type | Normal or Silent |
| Cutting result | Flat surface and even size |
| Processing Method | Silver Welded |
| Industry | Diamond tools |  |
Diamond Saw Blades for Granite Cutting - Diagonal Groove Segments
Diamond Saw Blades with Diagonal Groove Turbo Segments for Slab Edge Cutting of Granite, Sandstone, kinds of Hard Stones with quartz, Suitable for Bridge Cutting Machine, Manual Handling Cutting Machine or Table Cutting Machine.
Better cutting speed than normal segmented saw blades, water groove on the segments is better for fast coolant.
The following are the normal Specifications we are selling:
Code No.
Diameter (mm/Inch)
Hole(mm)
Segment Height (mm)
Segment No. (pcs/set)
Steel Blank Type
Welding Method
BW-SBG-03-01
250mm(10")
50/60
10.0/12
18
Normal & Silent
Silver Welded
BW-SBG-03-02
300mm(12")
50/60
10.0/12
21
BW-SBG-03-03
350mm(14")
50/60
10.0/12
24
BW-SBG-03-04
400mm(16")
50/60
10.0/12
28
BW-SBG-03-05
450mm(18")
50/60
10.0/12
32
BW-SBG-03-06
500mm(20")
50/60
10.0/12
36
BW-SBG-03-07
550mm(22")
50/60
10.0/12
38
BW-SBG-03-08
600mm(24")
50/60
10.0/12
42
.gif){kind=small}
Wet use only, Fast & Easy cutting, long life, very less or no chips, perfect performance.
The above specification is only for Referencether.Other specification is available according to customer's requirements.
Features:
Cutting Speed is faster than Normal Flat 40mm Length Segmented Saw Blades, there are four even five Diagonal Grooves on each side of Segment, which also can reduce the friction when the blade cut the Stone. Specially the Diagonal Groove is much helpful for the Coolant.
Diameter: 250mm-600mm, Diagonal Groove Type Segments, Length 40mm, height 10mm/12mm, Silver Welded.
Easy and smooth cutting for Hard, Medium Hard, Soft Granite without chips or with very less Chips, Long life and stable performance.
Kindly Noted:
When place order for Granite Cutting Saw Blades please inform:
Code No. of Granite Cutting Saw Blades
Diameter (Inch or mm)
Inner Hole/Bore Size (Inch or mm, 50mm or 60mm, or other size)
Installation hole (If, please send us Drawing)
Silent or None Silent Saw Blade?
Material Cutting: What type Granite, Sandstone, or other hard Stone?
Machine Powder/RPM (If possible)
Order Quantity & Expected Shipping Date
Special Requirements (If)
