| Product parameters |
| Name: | Normal Segmented Diamond Dry Cutters (Small Saw Blade) |
| Model Number: | BW-DC-01 |
| Diameter | From 105mm to 230mm |
| Type | Dry or Wet Use |
| Segment Height | 8mm 10mm |
| Usage | Cutting Granite, Marble, Sandstone, Limestone etc. |
| Industry | Diamond tools |
| Machine | Manual Handling Cutting Machine or Table Cutting Machine |
| Steel Blank Type | Normal or Silent |
| Cutting result | Flat surface and even size |
| Processing Method | Hot Sintered |  |
Diamond Dry Cutters - Normal Segmented Small Saw Blade
Normal Segmented Diamond Dry Cutters (Small Saw Blade), diameter from 4"(105mm) - 9"(230mm), for fast cutting kinds of hard, medium hard, soft stone, like Granite, Marble, Sandstone, Limestone etc., and other construction materials like Concrete, Asphalt, Ceramic, Porcelain, Bricks, etc.
Hot Sintered, Dry or Wet Use!
The following are the normal Specifications we are selling:
|
Code No. |
Diameter |
Segment Thickness |
Segment Height |
Bore (mm) |
|
BW-DC-01-01 |
105mm(4") |
1.8 |
8/10mm |
15.88mm(5/8") 20.00mm 22.23mm(7/8") 25.40mm(1") |
|
BW-DC-01-02 |
115mm(4.5") |
1.8 |
8/10mm |
|
|
BW-DC-01-03 |
125mm(5") |
2.0 |
8/10mm |
|
|
BW-DC-01-04 |
150mm(6") |
2.2 |
8/10mm |
|
|
BW-DC-01-05 |
180mm(7") |
2.2 |
8/10mm |
|
|
BW-DC-01-06 |
200mm(8") |
2.4 |
8/10mm |
|
|
BW-DC-01-07 |
230mm(9") |
2.6 |
8/10mm |
|
|
|
||||
The above specifications & photo is only for Reference, other or specialspecifications may be available as per customer's demand.
Safety First !
Please use the following before operating the cutting:
KIndly Noted：
When place order for Diamond Dry Cutters please inform:
Code No. of Diamond Dry Cutter
Diameter (Inch or mm)
Inner Hole / Bore Size (Inch or mm)
Material Cutting: What type Granite, Sandstone, or other hard Stone?
Machine Powder/RPM (If possible)
Order Quantity & Expected Shipping Date
Special Requirements (If)
