Multi Hole Steel Core 105mm-230mm Diamond Saw Wheel Cutting Plates Wheel Disk For Stone Concrete Tile Ceramic

Add / Delete to Basket

Product parameters

Name:	Multi Hole Steel Core 105mm-230mm Diamond Saw Wheel Cutting Plates Wheel Disk For Stone Concrete Tile Ceramic
Model Number:	BW-TSB-012
Segments Thickness:	1.8-2.6mm
Segment Width:	35-39.2mm
Diameter:	4-9 Inich
Size:	105mm-230mm
Segment Height:	8/10/12mm
Welding Technology:	Cold Pressed
Cutting Condition:	Wet Cut, Dry Cut
Machine:	Angle Grinder,Circular Saw,Table Saw, Etc.
Feature:	Multi Purpose, Multi Hole Steel Core, Fast Cutting

Product Description

Multi Hole Steel Core 105mm-230mm Diamond Saw Wheel Cutting Plates Wheel Disk For Stone Concrete Tile Ceramic

Specification:

The following specifications of Multi Hole Steel Core Cutting Plates Wheel Disk :

Diameter		Bore	Segment	Segment	Segment
mm	inch	Size(mm/inch)	Width(mm)	Thickness(mm)	Height(mm)
105	4”	16/20 22.23 25.4 50	35	1.8	8/10/12
110	4.3”		32.3	1.8	8/10/12
115	4.5”		38.3	1.8	8/10/12
125	5”		37.5	2.0	8/10/12
150	6”		33.5	2.2	8/10/12
180	7”		35	2.4	8/10/12
200	8”		39.2	2.4	8/10/12
230	9”		34.4	2.6	8/10/12

The above specifications & photo is only for Reference, other or special specifications may be available as per customer's demand.

Multi Hole Steel Core Cutting Plates Wheel Disk

Feature:

Customizable Circular Diamond Turbo Saw Blade

Multi Hole Steel Core Cutting Plates Wheel Disk is usually for cutting Ceramic or Porcelain Tiles.

1. Multi Hole Steel Core Cutting Plates Wheel Disk can dry use or wet use.

2. Narrow turbo design offers a faster, cleaner and more accurate cuts.

3. 1.8-2.6mm rim thickness for extended cutting life.

4. Cooling holes allow air to cool down the blade quickly and effectively.

Attention when use:

1. Before saw blade installed, pollutions adhering between saw blade and flange shall be removed,
when installing saw blade, the marked direction shall be kept consistent with the rotating
direction of electric tools, and flange shall be fastened by spanner attached to electric tools

2. Do not use any saw blade that has been deformed for being pressed of crashed

3. When operating, operator must wear safety helmet, safety footwear and goggles, protective glove,additionally, if necessary operator must use earplug, mask and so on

4. Electric tools shall have protective cover

Application:

Multi Hole Steel Core Cutting Plates Wheel Disk of hard and brittle materials such as concrete, refractory materials,stone, ceramics, etc.

Application machine:

Multi Hole Steel Core Cutting Plates Wheel Disk suitable for angle grinder,circular saw,masonry saw,table saw.

note:

1. It is recommended that the operator wear protective glasses, protective masks, work clothes, protective shoes, gloves and other protective equipment;

2. Tighten the installation according to the rotation direction indicated by the saw blade, and do not work in the reverse direction;

3. When dry cutting, please do not cut continuously for a long time, so as not to affect the service life and cutting effect of the saw blade;

4. When using wet slices, water should be added instead of curve cutting. Please use special arc cutting blades for cutting curves;

5. It is forbidden to use cutting discs for polishing operations, please use professional polishing discs for polishing;

6. If the saw blade is not used for cutting operations in accordance with the relevant requirements, a serious injury may occur.
