| Product parameters |
| Name: | Laser Welded Super Turbo Segmented Diamond Dry Cutters |
| Model Number: | BW-DC-L02 |
| Diameter: | From 105mm to 230mm |
| Type: | Dry or Wet Use |
| Segment Height: | 10mm |
| Segment Thickness: | From 2.4mm to 3.0mm |
| Usage: | Cutting kinds of hard, medium hard, soft stone, like Granite, Marble, Sandstone, Limestone etc. |
| Machine: | Manual Handling Cutting Machine or Table Cutting Machine |
| Steel Blank Type: | Normal or Silent |
| Cutting result: | Flat surface and even size |
| Processing Method: | Laser Welded |
| Industry: | Diamond tools |  |
Diamond Dry Cutters (Small Diameter Dry Cutting Diamond Saw Blade)
Laser welded - Spiral Turbo Segments
Laser Welded Super Turbo Segmented Diamond Dry Cutters (Small Saw Blade), diameter from 4"(105mm) - 9"(230mm), for fast cutting kinds of hard, medium hard, soft stone, like Granite, Marble, Sandstone, Limestone etc.
Also suitable for general purpose, such as concrete, asphalt, ceramic, bricks, etc.
Dry or Wet Use!
The following are the normal Specifications we are selling:
|
Code No. |
Diameter (mm/inch) |
Segment Size (mm) |
Segment No. (pcs/set) |
Welding Method |
|
BW-DC-L02-01 |
105mm(4") |
32x2.4x10 |
8 |
Laser Welded |
|
BW-DC-L02-02 |
115mm(4.5") |
32x2.4x10 |
9 |
|
|
BW-DC-L02-03 |
125mm(5") |
32x2.4x10 |
10 |
|
|
BW-DC-L02-04 |
150mm(6) |
32x2.4x10 |
12 |
|
|
BW-DC-L02-05 |
180mm(7) |
34x2.8x10 |
14 |
|
|
BW-DC-L02-06 |
200mm(8") |
34x2.8x10 |
16 |
|
|
BW-DC-L02-07 |
230mm(9") |
34x3.0x10 |
18 |
|
|
|
||||
|
|
The above specifications & photo is only for Reference, other or specialspecifications may be available as per customer's demand.
Safety First !
Kindly Noted：
Before mounting the saw blade ensure that the machine cannot start (pull out main plug).
Rotational direction arrow of the saw blade has to match the spindle rotational direction.
Not suitable for grinding – grinding can lead to serious injury through segment break outs.
Saw specification has to be appropriate for the material to be cut.
Do not tilt the saw blade in the cut.
Do not carry out any curved cuts.
Allow cooling down breaks, if saw blade is sparking heavily (use reciprocating cut).
Use protective clothing.
Please use the following before operating the cutting:
