Diamond vacuum brazed wire saw

Add / Delete to Basket

Product parameters

Name:	Diamond vacuum brazed wire saw
Model Number:	BW-VBWS-00
Product name	Vacuum brazed wire saw
Diameter	ø11.0mm-ø7.2mm
Bead length	12.5/11.0mm-9mm
Bead number	28/30/32(Pcs/num)
Grit	30#~40#
Reinforcement	Spring/Plastic

Product Description

Vacuum brazed wire saw

Vacuum brazed wire saw come with double arrow design and pattern-set diamond on steel body to extend tool life and make full use of diamonds for best cutting efficiency.Extra aggressive on marble and limestone quarrying, block squaring, profiling or slab cutting.Could be used wet or dry, best with wet cutting for tool life concern.

Vacuum brazed wire saw

There are normal specification of vacuum brazed wire saw:

Diameter (Inch/mm)	Bead Length (mm)	Bead Numbers (pcs/meter)	Grit Size(#)	Reinforcement	Application
ø11.0mm	12.5/11.0	28/30/32	30#~40#	Spring/Plastic	Quarrying/Block Squaring
ø10.0mm	12	28/30/32	30#~40#	Spring/Plastic	Quarrying/Block Squaring
ø8.8mm	11	28/30/32	30#~40#	Spring/Plastic	Stone Profiling
ø7.2mm	9	28/30/32	30#~40#	Spring/Plastic	Slab Cutting

The above specification just a reference for customers.Other specification can be ordered by clients.

Kindly noted:

The code of vacuum brazed wire saw(BW-VBWS-00)

Diameter(?)

Bead Length(?)

Bead Numbers(?)

Grit Size(?)

Reinforcement(?)
