Diamond Wire Saw for Stone Granite Marble Cutting

Add / Delete to Basket

Product parameters

Name:	Diamond Wire Saw for Stone Granite Marble Cutting
Model Number:	BW-DWS-00
Type	Dry or Wet Use
Diameter	7.2mm to 11.5mm
Fixing Type	Rubber,Spring,Plastic
Usage	Cutting granite, marble.,profiling
Machine	Wire saw machine
Advatage	Good sharpness
Cutting result	Small slot
work environment	Low-noisy,no-dust and safe operation
Performance	Hot Sintered and Electroplated
Performance	Hightly stable

Product Description

Diamond Wire Saw for Stone Granite Marble Cutting

At present, the diamond wire saws have already used more and more for

quarries. They have more advantage than traditional quarry operation. They

are high efficiency and high output and lower waste of quarry resource. They

can be used for great area cutting .The block is regular, without internal injury,

It is low-noisy, no-dust and safe operation.

The following are the normal Specifications we are selling:

Diameter (mm)	Fixing Type	Beads No.(pcs/M)		Purpose
Diameter (mm)	Fixing Type	Granite	Marble	Purpose
Ф11.5	Rubber	40	x	Granite Quarry
Ф11.5	Spring	x	28-33	Marble Quarry
Ф11.0	Rubber	40	x	Granite Quarry
	Spring	x	28-33	Marble Quarry
	Plastic	37	33	Block Squaring
Ф10.5	Plastic	37	33	Block Squaring
Ф10.0	Plastic	37	33	Block Squaring
Ф9.0	Plastic	37	33	Profiling, Slab Cutting
Ф8.8	Plastic	37	33	Profiling, Slab Cutting
Ф8.5	Plastic	37	33	Profiling, Slab Cutting, Multi-Wires
Ф8.2	Plastic	37	33	Profiling, Slab Cutting, Multi-Wires
Ф7.2	Plastic	37	33	Profiling, Slab Cutting, Multi-Wires

The above specification & photos is only for Reference, other specification or design can

be ordered by customers.

Diamond Wire Saw Type

Rubber Coating Type Plastic Coating Type

Spring Coating Type

The sawing speed is calculated by sawing depth (mm) per minute

1. The rotation of the wire should be regularly checked
2. The beads wear profile should be regularly inspected
3. The connections should be changed whenever excessively high wear of the

adjacent beads is noted and whenever it is necessary to apply pretorsion to

     the cable.
4. The cable tension is set to 250-300kg(4-5mmdiameter cable)
5. Adiust the liner speed of the wire to the material being sawn:
     Granite class 1—2: 25—30m/s
     Granite class 3—4: 22—26m/s
     Granite class  5: 20—24m/s
     Marble: 30—35m/s
     Abrasive stone: 30—35m/s
6. During the sharpening of a new wire ,the liner speed must be reduced by 2-3m/s
7. Water spraying between 15-25L/min

Kindly Noted:

when place order please inform the following:

Code No. of Diamond Wire

Diameter of the Wire (11mm, 10.5mm or 10.0mm)

Wire Type (Plastic or Rubber)

Granite Type (Hard, Medium, Soft, or Abrasive)

Order Quantity (How many Meters)

Wire Saw Machine Power (How many KW or HP of the motor)

Expected cutting speed and life(M2)

Expected shipping date
