Diamond Turbo Dry Cutters with 4 flange holes

Product parameters
Name: Diamond Turbo Dry Cutters with 4 flange holes
Model Number: BW-DC-W04
Diameter: From 105mm to 230mm
Type: Dry or Wet Use
Segment Height: 8mm
Segment Thickness: From 2.2mm to 2.6mm
Usage: Cutting kinds of hard, medium hard, soft stone, like Granite, Marble, Sandstone, Limestone etc.
Machine: Manual Handling Cutting Machine or Table Cutting Machine
Steel Blank Type: Normal or Silent
Cutting result: Flat surface and even size
Processing Method: Hot Sintered
Industry: Diamond tools

Product Description




105mm-150mm Diamond Turbo Dry Cutters with 4 flange holes.



There are 4 holes near the bore which is for installing flange purpose. The position and hole size is standard.



Hot Sintered, Dry or Wet Use.



The following are the normal Specifications we are selling:



Diameter

Hole(Bore)

Thickness Segment Height
105mm(4")

15.88mm(5/8")

20.00mm

22.23mm(7/8")

2.4mm

8mm

115mm(4.5")

2.4mm

8mm

125mm(5")

2.6mm

8mm

150mm(6")

2.6mm

8mm



The above specification & photo is only for Reference, other or specialspecification can be ordered by customers.



 Kindly Noted :



Safety First !



Before mounting the saw blade ensure that the machine cannot start (pull out main plug).
Rotational direction arrow of the saw blade has to match the spindle rotational direction.
Not suitable for grinding – grinding can lead to serious injury through segment break outs.
Saw specification has to be appropriate for the material to be cut.
Do not tilt the saw blade in the cut.
Do not carry out any curved cuts.
Allow cooling down breaks, if saw blade is sparking heavily (use reciprocating cut).
Use protective clothing.




Please use the following when operate the cutting:
