Diamond Rollers for Granite Calibrating

Product parameters
Name: Diamond Rollers for Granite Calibrating
Model Number: BW-DCR-00
Length: From 400mm to 600mm
Type: Wet Use
Diameter Size: 195mm,235mm
Usage: For calibrating Slabs or tiles surface
Machine: Automatic polishing and grinding machines
Water Quantity Needed: Medium
Grinding result: High gloss and lasting shining

Product Description


Diamond Rollers for Granite Calibrating

Granite Diamond rollers are used for calibrating Slabs or tiles surface evenly to adjust the thickness and balance of slabs or tiles surface.

Characterized by sharp Grinding, good wearing resistance, excellent chip
removal and low working noise.


Wet use only with sufficient water, Fast & Easy grinding, long life, perfect performance.



The following are the normal Specifications we are selling:



Length Diameter( mm ) Segmented Length ( mm ) Segment Size Roller Type Grit
Width Height
400mm 195/235 395 9mm 12mm  Spirals: 5-7 spirals
Rings: 11-22pcs
Rough
 Medium
 Fine
450mm 195/235 445 9mm 12mm
500mm 195/235 495 9mm 12mm
600mm 195/235 595 9mm 12mm


The above specification & photos is only for Reference, other specification or design can be ordered by customers.
