Your position: Home > Products > Stone Tools > Stone Grinding & Polishing Tools > Diamond Standard Stubbing Wheel > D86x20Tx50H Diamond Segmented Cyclone Gauging Wheel For Counter
Product parameters |
Description
1.D86x20Tx50H Diamond Segmented Cyclone Gauging Wheel For Counter are used for surface
milling and material removal for various granite and marble stone on CNC
or other machines.Their merits are high efficiency of production,accuracy
in shape and size.
2.It is be used before using the diamond proliing wheels.
3.It has high efficiency efficiency,long lifespan and good stable.
Normal size of diamond standard stubbing wheel:
Product code |
Diameter (mm) |
Segment height (mm) |
Inner hole (mm) |
Connection |
Grit No. |
Machine |
Specification of adapter |
BW- DSSW-01 |
50 |
20 |
10 |
Φ10-2+2Hole |
30/40# 60# 100# 200# |
CNC machine and arm radial machine |
D37×90L |
30 |
|||||||
40 |
|||||||
BW- DSSW-02 |
86 |
20 |
50 |
Φ50-3+3Hole |
D75×78L |
||
30 |
|||||||
40 |
|||||||
BW- DSSW-03 |
100 |
20 |
Φ50-3+3Hole |
||||
30 |
|||||||
40 |
Adapter of diamond standard stubbing wheel not be included.
Other more sizes could be customized after confirmation.
When order diamond standard stubbing wheels please confirm.
1.Code No. of diamond drain board wheel( BW-DSSW-02(20T))
2.Specification of diamond standard stubbing wheel (diameter ? Segment height ? Inner hole ?connection ?Grit? )
3.Do you need the adapter of the standard stubbing wheel?What size do you want?
4.Quantity(?)
