| Product parameters |
| Name: | Continuous Rim Diamond Dry Cutters (Small Saw Blades) |
| Model Number: | BW-DC-02 |
| Diameter | From 105mm to 230mm |
| Type | Dry or Wet Use |
| Segment Height | 8mm,10mm |
| Segment Thickness | From 1.8mm to 2.6mm |
| Usage | Cutting Granite, Marble, Sandstone, Limestone etc. |
| Machine | Manual Handling Cutting Machine or Table Cutting Machine |
| Steel Blank Type | Normal or Silent |
| Cutting result | Flat surface and even size |
| Processing Method | Hot Sintered |
| Industry | Diamond tools |  |
Diamond Dry Cutters - Continuous Rim Small Saw Blade
Continuous Rim Diamond Dry Cutters (Small Saw Blades), diameter from 4"(105mm) - 9"(230mm), for fast cutting kinds of hard, medium hard, soft stone, like Granite, Marble, Sandstone, Limestone etc., and other construction materials like Concrete, Asphalt, Ceramic, Porcelain, Bricks, etc.
Hot Sintered, Dry or Wet Use!
The following are the normal Specifications we are selling:
|
Code No. |
Diameter |
Segment Thickness |
Segment Height |
Bore (mm) |
|
BW-DC-02-01 |
105mm(4") |
1.8 |
8/10mm |
15.88mm(5/8") 20.00mm 22.23mm(7/8") 25.40mm(1") |
|
BW-DC-02-02 |
115mm(4.5") |
1.8 |
8/10mm |
|
|
BW-DC-02-03 |
125mm(5") |
2.0 |
8/10mm |
|
|
BW-DC-02-04 |
150mm(6") |
2.2 |
8/10mm |
|
|
BW-DC-02-05 |
180mm(7") |
2.2 |
8/10mm |
|
|
BW-DC-02-06 |
200mm(8") |
2.4 |
8/10mm |
|
|
BW-DC-02-07 |
230mm(9") |
2.6 |
8/10mm |
|
|
|
||||
The above specifications & photo is only for Reference, other or specialspecifications may be available as per customer's demand.
Safety First !
Please use the following before operating the cutting:
Kindly Noted ：
When place order for Dry Cutters please inform the following:
Diameter (Inch or mm)
Inner Hole Size (Inch or mm)
Use of saw blade (For Granite, or marble, or limestone, or Sandstone. or other material)
Code No.
Detailed Description with Photo (If your product not available to see from the above)
Quantity NO. (How many pcs)
Machine Powder/RPM (If possible)
Expected Shipping Date
Special Requirements (If)
For the user, the first step is to know cutting machine kind, as power HP, Rotary RPM, Max Cutting Depth and cutting material, and Judge Cutting with water or without water.
