China Factory Supplier 1200mm Diamond Saw Blade for Stone Cutting

Add / Delete to Basket

Product parameters

Name:	China Factory Supplier 1200mm Diamond Saw Blade for Stone Cutting
Model Number:	BW-SBM-01-1200
Place of Origin:	Fujian, China
Brand Name:	BOREWAY
Model Number:	BW-SBM-01-1200
Diameter:	1200mm
Segment length:	24mm
Segment No.:	80pcs
Blade Material:	Diamond
Segment Thickness:	6.5 to 7.5mm
Segment height:	12,15,20mm
Application	For cutting granite marble,sandstone,limestone,lava,concrete,mine

Product Description

China Factory Supplier 1200mm Diamond Saw Blade for Stone Cutting

Feature:

1.Fast cutting,long life,Stable performance, High grade of diamonds

2.Different bonds are for different applications,precise segment size

3.Working safe, quiet, and precise, reducing cutting,working time

4.Great adaptability,No chipping

Description:

Diamond segments or rims are made up of a mixture of diamonds and metal powders. factory supplier 1200mm diamond saw blade used in blades are almost exclusively manufactured diamonds in various grit size and quality grades.
In the manufacturing process, the metal powder and diamond grit mixture is hot pressed at high temperatures to form a solid metal alloy (called the bond or matrix) in which the diamond grit is retained.
The segment or rim is slightly wider than the blade core. This allows the cutting edge to penetrate through the material while protecting the steel body.
The application of bond (or Matrix)
1. Typically the following rule applies :
2. For hard materials : use soft bonds.
3. For soft materials : use hard bonds.

Example:

Limestone is soft and abrasive therefore we would use a hard bonded blade. Reinforced concrete with river pebble aggregate is hard therefore we would use a soft bonded blade.

Hard Bond:
Means that the compilation of metals when sintered together forms a segment of approximately 105 to 120 HRB (hardness) and is very resistant to the soft abrasive materials being sawn, thus releasing diamond at the appropriate rate.
Hard bonds typically consist of the following metal powders – cobalt, iron, tungsten carbide and are grey to dark grey in colour.

Soft Bond:
Means that the compilation of metals when sintered together forms a segment of approximately 90 to 105 HRB (hardness) and allows the segment to wear quicker thus retaining diamond on the cutting surface.
Soft bonds typically consist of the following metal powders - copper, bronze and cobalt, and are generally bronze to light silver in colour.

Specification:

The followings are our normal sizes of our factory supplier 1200mm diamond saw blade:

Single/Multi blades segment dimension
Diameter:		Segment length:	Segment Thickness:	Segment height:	Segment No. (pcs/set)
inch	mm	Segment length:	Segment Thickness:	Segment height:	Segment No. (pcs/set)
36”	900	24	6.0/6.8	12/15/20	64
40”	1000	24	6.4/7.2	12/15/20	70
48”	1200	24	6.5/7.5	12/15/20	80
56”	1400	24	7.5/8.5	12/15/20	92
64”	1600	24	8.4/9.2	12/15/20	108
72”	1800	24	9.2/10	12/15/20	120
80”	2000	24	9.5/10.5	12/15/20	128
88”	2200	24	10.5/11.5	12/15/20	132
100”	2500	24	11.5/12.5	12/15/20	140
120”	3000	24	12.5/13.5	12/15/20	160
140”	3500	24	12.5/13.5	12/15/20	180
Other specifications of diamond segment are available upon request.

FAQ

1. How could we know the quality, if we want to order your products?
Please just test them with a very small order, then you will know the quality.

At present,so many people in the world to use Chinese products, because

of the high quality and most competitive prices. We are professional

manufacturer in supplying diamond tools for more than 8 years. Anyway,

confirming our products quality, a small trial order for testing will be necessary.
2.Can you offer free samples?
We don’t offer free samples, according to our many years experience, we

think people get the samples by paying, they will cherish and appreciate

more what they get. But we are willing to give our potential customers a

special discount which they are used to do a testing. It is very important

to give us feedback, we appreciate it.
3.Does your company accept custom-made?
Surely, we accept it. Including different color, grit etc. We also can mark

your ownlogo and brand on the pad. Any new productsyou want us to

produce for you, just send us your drawing or sample, we will produce

the same one. We will not sell this kind of products to other customers

only if we get your permission.

ABOUT FEEDBACK

Please confirm the receipt of the products after you got them. If you

have any question about the products you received, please

contactus in time and we will try our best to solve the problem

and make you satisfied.
