Boreway Silver Welding Crown Shape Core Drill Segment For Reinforce Concrete Manufacturer

Add / Delete to Basket

Product parameters

Name:	Boreway Silver Welding Crown Shape Core Drill Segment For Reinforce Concrete Manufacturer
Model Number:	BW-DS-DB-C01-14
Place of Origin:	Fujian, China
Brand Name:	BOREWAY
Segment width:	3.0mm
Segment height:	10mm
Production technology:	Sintered
Diameter:	2inch(52mm)
Welding:	High frequency welding,Silver welded
Application:	Cured reinforced concrete with hard to soft aggregates

Product Description

Boreway Silver Welding Crown Shape Core Drill Segment For Reinforce Concrete Manufacturer

Descriptions:

Diamond Segments of Drill Bits - Crown Shape

Welding crown shape core drill segment of small diameter drill bits with crown of 22mm-52mm provide smooth drilling and avoid segments loosing. High Concentration of diamond offers long drilling life.

Welding Type: Silver welding.

Wet Use.

Specifications:

The following specifications of Welding crown shape core drill segment:

Code No.	Diameter	Segment Width	Segment Height
BW-DS-DB-C01-01	14mm	2.5mm	10mm
BW-DS-DB-C01-02	16mm (5/8”)	2.5mm	10mm
BW-DS-DB-C01-03	18mm	2.5mm	10mm
BW-DS-DB-C01-04	3/4"(20mm)	2.5mm	10mm
BW-DS-DB-C01-05	7/8"(22mm)	2.5mm	10mm
BW-DS-DB-C01-06	1"(25mm)	2.5mm	10mm
BW-DS-DB-C01-07	1.18"(29mm)	2.5mm	10mm
BW-DS-DB-C01-08	1-1/4"(32mm)	2.5mm	10mm
BW-DS-DB-C01-09	1-3/8"(35mm)	2.5mm	10mm
BW-DS-DB-C01-10	1-1/2"(38mm)	3.0mm	10mm
BW-DS-DB-C01-11	1.63"(42mm)	3.0mm	10mm
BW-DS-DB-C01-12	1-3/4"(45mm)	3.0mm	10mm
BW-DS-DB-C01-13	1.88"(48mm)	3.0mm	10mm
BW-DS-DB-C01-14	2"(52mm)	3.0mm	10mm

Other size is available as per requst.

Advantages:

1. Welding crown shape core drill segment adopts diamond sheet material and metal matrix (Ti + Cr + Ni + CO, etc.) to form chemical bond, which can reduce threshing, improve cutting edge and prolong service life.

2. Change single drilling to combination of grinding and cutting edge drilling (high strength diamond), optimize the drilling performance;

3. Good sharpness of cutter head, fast drilling speed and high efficiency;

4. Good wear resistance coefficient, long service life and high comprehensive cost performance!

Note: the operator is required to add a certain amount of cooling water, and the spray flow should be large, so that it has better cooling effect, so as to improve the service life of the drill and reduce the cost!

Applications:

welding crown shape core drill segment cured reinforced concrete with hard to soft aggregates, green concrete or abrasive material.

Machine for making cutter Segment:

20mm height black diamond granite cutting segment tips for make machine

Machine for welding the cutter segment base:

Boreway Silver Welding Crown Shape Core Drill Segment For Reinforce Concrete Manufacturer
