Boreway Prive Factory Price Sharp Conventional Granite Cutting In Diamond Saw Blade

Add / Delete to Basket

Product parameters

Name:	Boreway Prive Factory Price Sharp Conventional Granite Cutting In Diamond Saw Blade
Model Number:	BW-DSG-01-09
Segment No.:	64pcs
Hole:	60/80MM
Saw blade thickness:	5(5.5)MM
Max.RPM:	1050 RPM
Diameters:	900MM,36Inch
Segment Size:	40x8x10MM
Machine:	For Bridge Cutting Machines
Cutting Material:	Marble Sandstone,Various Hard Stone

Product Description

Boreway Sandstone Marble Sharp 40x8x10mm Diamond Tip Flat Granite For Sale

Advantage:

1. Sharp diamond tip flat granite in diamond saw blade has good sharpness, fast cutting speed and high cutting efficiency.

2. Good wear resistance, long service life and high comprehensive cost performance.

3. Sharp Diamond Tip Flat Granite In Diamond Saw Blade are Fast cutting, small cutting seam, the cut stone surface is flat and

even in size.

4.By changing single grinding into the combination of grinding and cutting, the sawing performance is optimized.

Feature:

1. To get the even and smooth slab

2. To produce slabs in very short time

3. To have low- noise and friendly surroundings

4. Easy manipulation and with low cost

5. Always low power consume and lesser raw material waste

6 .Sharp diamond tip flat granite in diamond saw blade good sharpness and high cutting efficiency with long life

7. Stable cutting with narrow cutting gap,stone waste reduction

8.Flexibility,unlimited by the size of work piece,can be used for dressing and forming for abnormal profiles.

Specification:

The following are normal specifications Sharp diamond tip flat granite in diamond saw blade:

Diameter		Thickness	Teeth	Segment Size			Hole	Max. RPM
Inch	mm	mm	Pcs/set	L	W	H	mm	RPM

64	900	5.0(5.5)	64	40	7.5（8.0）	10/12	60/80	1050

Specially designed tools are available for any standard application. We can

Tailor your tools to your specific needs

Sharp diamond tip flat granite in diamond saw blade

PS:A certain amount of cooling water should be added when cutting the cutter head, and the spray water flow should be large, so that it has a better cooling effect!

In addition, the speed of the combined saw blade is required to be 280-320 rpm, and the trolley can not be transported too fast!

Product Detail:

1.Different market need different quality and sizes. We can make all kinds of sizes and quality or price according your requirement.
2. We can make many kinds of segments for cutting granite, marble, concrete and other industrial materials.
3. For Multi-balde for block saw,gang saws, single saw and so on.

Application:

Sharp diamond tip flat granite in diamond saw blade with normal flat shape of circular saw blades for slab edge cutting of Marble,Granite, Sandstone, various hard stone with quartz.

1. If the material is hard, the bond of the diamond segments should be softer.

Because diamonds will become blunt when cutting hard material. Softer bond can be

worn down with the blunt diamonds faster, then make new diamonds beneath be more easily exposed to participate in cutting

2. If the material is relatively softer, the bond should be harder.

The diamonds can last longer in this care. The harder bond wears slower, so that it can hold the diamonds also longer. This can make better use of the diamonds and prolong the diamond tool's service life.

Application machine:

Sharp diamond tip flat granite in diamond saw blade silver welding by high frequency welding machine.

550mm flat shape blade diamond customized segments is wet use

High frequency silver welded machine is recommended instead of welding by fire.

Don’t weld diamond segment for a long time, just a few minutes, otherwise the diamond inside might be damaged because of the high temperature, which will affect the cutting performance of the granite segment greatly.

Relatsd Products:

Multi Blade Diamond Segment	W Shape Edge Cutting Diamond Segment for Granite	1400mm Diamond Cutting Tools Marble Block Diamond Segments

Please try best to offer below information when you are placing order:

Diam.: (inch or mm)

Segment Size (LxWxH, and thickness of steel core if possible)

Segment Formation (sandwich type or multiple line type)

Welding technology ( Silver Welding by high frequency machine, or Laser weldng)

Cutting target (for granite, sandstone or other hard stone including quartz)

Order quantity (how many pcs of blade or how many sets of segment)

Machine power (motor/rotation speed if possible)

Feeding speed (meter/minute)

Expected cutting depth(mm, at every turn, to and from)

Cooling system(water cooling or oil cooling, is it including coolant, the rate, liter/m )

Expected delivery time

About us:

Our serice:

1. Low order quantity: It can meet the test order you need.

2. Fast delivery: We get great discounts from freight forwarders.
3. OEM Acceptable: We can produce according to your samples or drawings.
4. Good quality: We have a strict quality control system. Has a good reputation in the market.
5. Good service: We regard our customers as God with a high degree of professionalism and enthusiasm.

FAQ:

1. If we want to order your product, how do we know your quality?

Please test in a very small order and then you will know the quality. Now, so
Many people in the world use Chinese products because of their high quality and high quality.
competitive price. We are a professional diamond tool manufacturer.
In any case, for more than 8 years, confirm the quality of our products, small test orders will be tested
necessary.

2.Can you provide samples for free?
We do not provide free samples. Based on years of experience, we believe that people will get them.
By paying for samples, we will cherish and appreciate the more they get. We would have been
Be prepared to offer our potential customers a special discount for participating in the test.
It is very important to provide feedback to us and we will be very grateful.

3. Does your company accept customization?
Of course, we accept it. Includes different colors, gravel, etc. We can also tag your own logo
And the brand on the board. You want us to produce any new products for you, just send us your products.
Drawing or sample, we produce the same. We will not sell such products to others
Only customers can get a license.

Plese note:

1. Please provide items before purchase.

2. Please provide the model number before purchase.

3. Other specifications can be customized according to requirements.

-Lyon Chang-
Fujian Nan'an Boreway Machinery Co.,Ltd.

Tel,Wechat,WhatsApp: +86 18650679939
E-mail: boreway@boreway.com
