| Product parameters |
| Name: | Arix (Matrix) Diamond segements for Granite Cutting |
| Model Number: | BW-DSG-09 |
| Type | Wet cutting |
| Segment Height | 10.0mm,12mm,15mm |
| Diameter | From 250mm to 800mm |
| Segment Length | 40mm |
| Segment Structure | Sandwich or 1-Layer |
| Usage | Cutting Granite, Sandstone, kinds of hard Stone with quartz |
| Machine | Bridge Cutting Machine,Manual Handling Cutting Machine or Table Cutting Machine |
| Welding Method | Silver Welded |
| Performance | Hightly stable |
| Advatage | Good sharpness and Long lifespan |
| Cutting result | Flat surface and even size |  |
Arix (Matrix) Diamond segements for Granite Cutting
Arix Diamond Segmented of 250mm -800mm circular Saw Blades for Slab Edge Cutting of Granite, Sandstone, kinds of Hard Stones with quartz, Suitable for Bridge Cutting Machine, Manual Handling Cutting Machine or Table Cutting Machine.
Much better cutting speed & cutting life than normal segmented saw blades.
Wet use only, Fast & Easy cutting, long life, very less or no chips, perfect performance.
The following are the normal Specifications we are selling:
|
Code No. |
Diameter (mm/Inch) |
Hole (mm) |
Segment Height (mm) |
Segment No. (pcs/set) |
Steel Blank Type | Welding Method |
|
BW-DSG-09-01 |
250mm(10") |
50/60 | 10/12/15 |
18 |
Normal
or
Silent |
Silver Welded |
|
BW-DSG-09-02 |
300mm(12") |
50/60 | 10/12/15 |
21 |
||
|
BW-DSG-09-03 |
350mm(14") |
50/60 | 10/12/15 |
24/25 |
||
|
BW-DSG-09-04 |
400mm(16") |
50/60 | 10/12/15 |
28 |
||
|
BW-DSG-09-05 |
450mm(18") | 50/60 | 10/12/15 |
32 |
||
|
BW-DSG-09-06 |
500mm(20") |
50/60 | 10/12/15 |
36 |
||
|
BW-DSG-09-07 |
550mm(22") |
50/60 | 10/12/15 |
38 |
||
|
BW-DSG-09-08 |
600mm(24") |
50/60 | 10/12/15 |
42 |
||
|
BW-DSG-09-09 |
700mm(28") |
50/60 | 10/12/15 |
50 |
||
|
BW-DSG-09-10 |
750mm(30") |
50/60 | 10/12/15 |
50 |
||
|
BW-DSG-09-11 |
800mm(32") |
50/60 | 10/12/15 |
46 |
||
 |
||||||
The above specification & photos is only for Reference, other specification or design can be ordered by customers.
Kindly Noted :
Please use high frequency Silver Welded machine instead of Fire to make the brazing, the welding time is only a few seconds, otherwise the diamond inside the segments will probably be damaged by the high temperature, then the cutting performance will be Reduced!
