| Product parameters |
| Name: | 900mm to 3500mm Diamond Circular Saw Blades for Granite Block Cutting |
| Model Number: | BW-SBGB-00 |
| Diameter | 900mm to 3500mm |
| Segment Structure | Multi-Layers,Sandwich |
| Usage | Cutting Granite, Sandstone, Kinds of Hard Stones with quartz |
| Advatage | Good sharpness and Long lifespan |
| Performance | Hightly stable |
| Machine | Bridge Cutting Machine and Single Arm Machine |
| Steel Blank Type | Normal or Silent |
| Cutting result | Flat surface and even size |
| Processing Method | Silver Welded |  |
900mm-3500mm Diamond Circular Saw Blades for Granite Block Cutting
Diamond Segmented Circular Saw Blades for Block Cutting of Granite, Sandstone, Slate, Kinds of Hard Stone with quartz, Suitable for Bridge Cutting Machine and Single Arm Machine.
Welding method: Silver welding Wet use only with sufficient water, Fast & Smooth cutting, long life, perfect performance. The following are the normal Specifications we are selling:
|
Diameter (mm) |
Segment Dimension (L × W × H) |
Steel Core Thickness |
Segment No. |
Segment Structure | ||
|
Length |
W (Taper Type) |
Height |
||||
|
900 |
24 |
7.0/6.5 |
10/12/15/20 |
5.0mm |
64 |
Multi-Layers
or Sandwich
|
|
1000 |
24 |
7.0/6.5 |
10/12/15/20 |
5.0mm |
70 |
|
|
1100 |
24 |
7.4/6.8 |
12/15/20 |
5.5mm |
74 |
|
|
1200 |
24 |
7.5/7.0 |
12/15/20 |
5.5mm |
80 |
|
|
1300 |
24 |
8.0/7.5 |
12/15/20 |
6.0mm |
88 |
|
|
1350 |
24 |
8.4/7.7 |
12/15/20 |
6.0mm |
88 |
|
|
1400 |
24 |
8.5/8.0 |
12/15/20 |
6.5mm |
96 |
|
|
1600 |
24 |
9.0/8.7/8.4 |
12/15/20 |
6.5mm |
104/108 |
|
|
1700 |
24 |
9.4/8.9/8.4 |
12/15/20 |
7.0mm |
112 |
|
|
1800 |
24 |
9.5/9.0 |
12/15/20 |
7.0mm |
120 |
|
|
2000 |
24 |
10.5/10/9.5 |
15/20 |
8.0mm |
128 |
|
|
2200 |
24 |
11.5/11/10.5 |
15/20 |
8.5mm |
132/136 |
|
|
2500 |
24/30 |
12/11.5/11 |
15/20/25/30 |
9.5mm |
140 |
|
|
2700 |
24/30 |
12/11.5/11 |
15/20/25/30 |
9.5mm |
140 |
|
|
3000 |
24/30 |
12.5/12/11.5 |
15/20/25/30 |
10.0mm |
160 |
|
|
3500 |
24/30 |
13/12.5/12 |
15/20/25/30 |
10.0mm |
180 |
|
The above specifications and photos is only for Reference, other or special specification can be ordered by customers.
Noted:
Warning: Please use high frequency Silver Welded machine to make the brazing if you only order diamond segments, and not to use Fire to braze the segment to the saw blank, otherwise the diamond will be damaged then the cutting performance will be influenced(Reduced)!
Recommendation: Please put 1.0%-1.5% chemical material(Coolant Material) into the water to increase the cutting speed & life.
When place order for saw blades please inform the following:
Diameter (Inch or mm)
Inner Hole Size (Inch or mm)
Installation hole (If, need drawing)
Segment No. (how many pcs segment per blade)
Segment Size (L x W x H, if possible please inform Steel Core Thickness)
Use of saw blade (For Granite, or marble, or limestone, or Sandstone. or other material)
Quantity NO. (How many pcs, or how many sets segments)
Machine Powder/RPM (If possible) Feed Speed (M/Minute)
Expected Cutting Depth (how many mm per time, forward or backward)
If only order segments please inform the following:
Diameter (Inch or mm) Segment No. (how many pcs segment per blade)
Segment Size (L x W x H, if better to inform the Steel Core Thickness)
Special Requirements (If)
