Your position: Home > Products > Stone Tools > Stone Cutting Tools > Marble Block Cutting Blades > 900mm to 2000mm Diamond Saw Blade for Marble Cutting
| Product parameters |
| Name: | 900mm to 2000mm Diamond Saw Blade for Marble Cutting |
| Model Number: | BW-SBMB-00 |
| Diameter | 900mm to 2000mm |
| Type | Wet Use |
| Usage | Cutting Marble, Limestone, Slate, Kinds of Soft Stones without quartz |
| Machine | Bridge Cutting Machine, Single Arm Machine |
| Industry | Diamond tools |
| Advatage | Good sharpness and Long lifespan |
| Performance | Hightly stable |
| Steel Blank Type | Normal or Silent |
| Cutting result | Flat surface and even size |
| Processing Method | Silver Welded |  |
900mm-2000mm Diamond Saw Blade for Marble Cutting
Diamond Segmented Circular Saw Blades for Block Cutting of Marble, Limestone, Slate, Kinds of Soft Stone without quartz, Suitable for Bridge Cutting Machine, Single Arm Machine.
Welding method: Silver welding
Wet use only with sufficient water, Fast & Smooth cutting, long life, perfect performance.
The following are the normal Specifications we are selling:
|
Diameter (mm) |
Segment Dimension (L × W × H) |
Steel Core Thickness |
Segment No. |
Segment Structure | ||
|
Length |
W (Taper Type) |
Height |
||||
| 900 | 24 | 6.5 | 8/10/12 | 5.0mm | 64 |
Mixed Powder or Sandwich |
| 1000 | 24 | 7.0 | 8/10/12 | 5.0mm | 70 | |
| 1200 | 24/40 | 7.5 | 8/10/12 | 5.5mm | 80 | |
| 1300 | 24/40 | 8.0 | 8/10/12 | 6.0mm | 88 | |
| 1350 | 24/40 | 8.0 | 8/10/12 | 6.0mm | 88 | |
| 1400 | 24/40 | 8.5 | 8/10/12 | 6.5mm | 96 | |
| 1600 | 24/40 | 9.0 | 8/10/12 | 6.5mm | 104/108 | |
| 1800 | 24 | 9.5 | 10/12 | 7.0mm | 120 | |
| 2000 | 24 | 10.5 | 10/12 | 8.0mm | 128 | |
The above specifications and photos is only for Reference, other or special specification can be ordered by customers.
Kindly Noted:
Please use high frequency Silver Welded machine to make the brazing if you only order diamond segments, and not to use Fire to braze the segment to the saw blank, otherwise the diamond will be damaged then the cutting performance will be influenced(Reduced)!
When place order for block cutting diamond saw blades please inform the following:
Diameter (Inch or mm)
Inner Hole Size (Inch or mm)
Installation hole (If, need drawing)
Segment No. (how many pcs segment per blade)
Segment Size (L x W x H, if possible please inform Steel Core Thickness)
Use of saw blade (For Granite, or marble, or limestone, or Sandstone. or other material)
Quantity NO. (How many pcs, or how many sets segments)
Machine Powder/RPM (If possible)
Feed Speed (M/Minute)
Expected Cutting Depth (how many mm per time, forward or backward)
Coolant System (Water or Oil, how many liters/Minute, etc.)
Expected Shipping Date
Special Requirements (If)
If only order block cutting diamond segments please inform the following:
Diameter (Inch or mm)
Segment No. (how many pcs segment per blade)
Segment Size (L x W x H, if better to inform the Steel Core Thickness)
Use of saw blade (For Granite, marble, limestone, Sandstone. or other material)
Quantity NO. (how many sets segments)
Machine Powder/RPM, Feed Speed, Normal Cutting Depth (If possible)
Expected Shipping Date
Special Requirements (If)
