| Product parameters |
| Name: | 400mm Diamond Segments with 2 U Slot for Marble Cutting |
| Model Number: | BW-DSM-04 |
| Type | Wet Use only |
| Segment Height | 10.0mm |
| Diameter | 400mm |
| Segment Length | 40mm |
| Segment Structure | with 2 U Slots Taper or Flat |
| Usage | Cutting Marble, limestone and other soft stone |
| Machine | Bridge Cutting Machine,Manual Handling Cutting Machine or Table Cutting Machine |
| Welding Method | Silver Welded |
| Performance | Hightly stable |
| Advatage | Good sharpness and Long lifespan |
| Cutting result | Flat surface and even size |  |
400mm Diamond Segments with 2 U Slot for Marble Cutting
Diamond Segment With 2 U Slot of 250-800mm circular saw blades for Slab Edge Cutting of Marble, Limestone, Slate, kinds of Soft Stone without quartz.
Easy and Free Cutting Kinds of Marble, Hard, Medium, Soft...
Silver Welding and Wet Use only.
Much better cutting speed & cutting life than normal segmented saw blades.
The following are the normal Specifications we are selling:
|
Diameter (mm/Inch) |
Segment Size (mm) |
Segment No. (pcs/set) |
Structure | Material Cutting |
|
400mm(16") |
40x3.8x10mm |
28 |
with 2 U Slots
Taper or Flat |
Marble, limestone and other soft stone |
The above specification & photos is only for Reference, other specification or design can be ordered by customers.
1. Why design this shape for marble segments?
The competition of normal segments is already very cruel in the world, this request Segments manufacturers to find more sales point and produce better performance products. According to the requirements of our customer from Italy, we studied the
segment bond (powder component) and designed this shape segment by one week.
2. The other size segments of this shape is available?
This 2 U slot shape is available for most size segments of saw blade diameter from 250mm-800mm with 10 or 12mm height. If the model is not available from our store, we need more days for the production.
3. What is the advantage of using this shape segments?
Under same segment bond condition, short length means less resistance when the segment is under cutting marble, 1 U slot is very good for the cutting speed, but 2 U slots will reduce the maximum resistance, and 2 slots is much helpful for fast coolant, due to these two reasons this
shape segment can brings most efficient cutting speed, and cutting will be very smooth without chips.
Kindly Noted ：
Please use high frequency Silver Welded machine instead of Fire to make the brazing, the welding time is only a few seconds, otherwise the diamond inside the segments will probably be damaged by the high temperature, then the cutting performance will be Reduced!
