| Product parameters |
| Name: | 250mm Diamond Surface Grinding Disc For Concrete With L Segment grinders |
| Model Number: | BW-GD-01 |
| Diameter: | 250mm |
| Segment height: | 10mm |
| Segment width | 10mm |
| Type | Abrasive Disc |
| Segment No. | 10 or 20 Segments |
| Machine: | Diamond's disc grinders (floor grinding machines) |
| Industry: | Diamond tools |
| Application: | For grinding green concrete and asphalt |
| Usage: | dry and wet use |
| Bond Type: | Soft, Medium, Hard. |
| Grinding result: | Flat surface and even size |  |
Surface Grinding Disc - L-Segmented - for Barranca Diamond's disc grinders
This grinding Disc (plate) are designed to give rough concrete surfaces the smoothest finish in the quickest time. This grinding discs are engineered with Balance Technology to improve machine vibration during application. It ideal for smoothing rough areas, surface irregularities, floor grinding, surface preparation, polishing, refinishing, as well as removing epoxies, resins, urethane and other concrete coatings.
Available in either 10 or 20 segment configurations.
Hard bond is for grinding green concrete and asphalt. Soft bond is for grinding old or cured concrete.
May be used on Barranca Diamond's disc grinders (Floor grinding machines).
Dry or Wet Use! Bond Type: Soft, Medium, Hard.
10 Segments Type 20 Segments Type
Less life but faster grinding speed.
Code No. Diameter Segment Height Segment Width Segment No. BW-GD-01-01 10"(250mm) 10 10 10 BW-GD-01-02 10"(250mm) 10 10 20
The above specification & photos is only for Reference, other specification or design can be ordered by customers.
Kindly Noted ：
When place order for Surface Grinding Disc please inform the following:
Diameter (Inch or mm)
Inner Hole Size (Inch or mm)
Use of Grinding Cup Wheels (For Granite, or marble, or limestone, or Sandstone. or other material)
Code No. of Diamond Grinding Cup Wheels
Grit No. (Rough, Medium, or Smooth)
Quantity NO. (How many pcs)
Expected Shipping Date
Detailed Description with Photo (If your product not available to see from the above)
Special Requirements (If)
