Boreway 3m Circular Wet Use Saw Blade Diamond Tip for Cutting Granite On Sale

Add / Delete to Basket

Product parameters

Name:	Boreway 3m Circular Wet Use Saw Blade Diamond Tip for Cutting Granite On Sale
Model Number:	BW--DSGB-02-15
Place of Origin:	Fujian, China
Brand Name:	Boreway
Seg.No.:	160pcs
Usage:	Wet use
Shape:	V shape
Diameter of saw blade:	3000mm
Size:	24X12.5X20mm
Segment bond:	Soft and hard segment bond
Application:	Stone,Granite,Limestone,etc

Product Description

Boreway 3m Circular Wet use Saw Blade Diamond Tip for Cutting Granite on Sale

Feature:

1. 3m circular wet use saw blade diamond tip for diameter from 900mm to 3500mm

2. Special powder mixture for each cutting of hard, medium hard, soft, and abrasive granite
3. Sandwich or multi-layered segment reduce side friction
4. Specification for your reference, customized size are available
5. 2m circular wet use saw blade diamond tip for single circular saw blade and multi-blade cutter,wire saw blades

Advantage:

1. Long cutting life and stable performance.

2. Segment is very sharp, high efficiency.

3. Advanced production process for sintering.

4. Strict product quality inspection processes.

5. Using high quality raw materials, imported cobalt powder and nickel powder, and high-quality diamond single crystals

6. 3m circular wet use saw blade diamond tip for cutting granite in high speed without chipping.

Specification:

The following are normal specifications 3m circular wet use saw blade diamond tip:

Code No.	Diameter (mm)	Segment Dimension (L × W × H)			Segment No.
		Length	Width (Taper Type)	Height
BW-DSGB-02-15	3000	24/30	12.5/12/11.5	20/25	160
			13/12.5/12/11.5	30

Specially designed tools are available for any standard application. We can

Tailor your tools to your specific needs

PS:A certain amount of cooling water should be added when cutting the cutter head, and the spray water flow should be large, so that it has a better cooling effect!

In addition, the speed of the combined saw blade is required to be 280-320 rpm, and the trolley can not be transported too fast!

Product Detail:

3m circular wet use saw blade diamond tip

Application:

3m circular wet use saw blade diamond tip for granite cutting used for single or multi circular saw blade from 900mm to 3500mm, Cutting of Granite, Sandstone, various hard stone with quartz.

1. If the material is hard, the bond of the diamond segments should be softer.

Because diamonds will become blunt when cutting hard material. Softer bond can be

worn down with the blunt diamonds faster, then make new diamonds beneath be more easily exposed to participate in cutting

2. If the material is relatively softer, the bond should be harder.

The diamonds can last longer in this care. The harder bond wears slower, so that it can hold the diamonds also longer. This can make better use of the diamonds and prolong the diamond tool's service life.

Application machine:

3m circular wet use saw blade diamond tip

High frequency silver welded machine is recommended instead of welding by fire.

Don’t weld diamond segment for a long time, just a few minutes, otherwise the diamond inside might be damaged because of the high temperature, which will affect the cutting performance of the granite segment greatly.

Relatsd Products:

Multi Blade Diamond Segment	W Shape Edge Cutting Diamond Segment for Granite	1400mm Diamond Cutting Tools Marble Block Diamond Segments

Please try best to offer below information when you are placing order:

Diam.: (inch or mm)

Segment Size (LxWxH, and thickness of steel core if possible)

Segment Formation (sandwich type or multiple line type)

Welding technology ( Silver Welding by high frequency machine, or Laser weldng)

Cutting target (for granite, sandstone or other hard stone including quartz)

Order quantity (how many pcs of blade or how many sets of segment)

Machine power (motor/rotation speed if possible)

Feeding speed (meter/minute)

Expected cutting depth(mm, at every turn, to and from)

Cooling system(water cooling or oil cooling, is it including coolant, the rate, liter/m )

Expected delivery time
