Resin filled CNC finger cutter bit

Product parameters
Name: Resin filled CNC finger cutter bit
Model Number: BW-CFB-05
Dimeter 25mm
Segment length 45mm
Connection 5/8"-11
Type Resin filled
Use Wet use
Usage For griding or drilling the granite marble or counter
Machine CNC or Radial Arm machines

Product Description


Resin filled CNC finger cutter bit

Resin filled CNC finger cutter bits are usually use after diamond core drill bits,fast removing

dust,diamond sink wheel.

Resin filled CNC finger cutter bits are ideal for fast stock removal as well as truing up saw lines,

which is designed to cut granite, engineered stone and marble,counter tops, kitchen tops and basins.

Resin filled finger cutter  bits are usually mounted on CNC or Radial Arm machines, for hole

grinding, anchor and blind hole.

Center water feed holes in each bit.

Wet use only.



Resin filled CNC finger cutter bit

The following are the normal specifications about resin filled CNC finger cutter bit:
Diameter
Bore (mm)
Segment Length
Segment No.
20mm (3/4")
1/2 Gas
(Male Thread)
40mm
45mm
50mm
60mm
4-6pcs
25mm (1")
30mm (1-1/4")
35mm (1-3/8")
40mm (1-5/8")
50mm (2")
60mm (2-3/8")
The above the specification just a reference for clients.Other specification can be order by clients.


Kindly noted:

When order diamond finger bit please Confirm.
Code No. of diamond finger bit (BW-CFB-04?)
Diameter(?)
Bore(?)
Segment length(?)
Segment number(?)
Quantity(?)
