Product parameters |
Diamond Segments of Drill Bits - Turbo Shape
Diamond segments Turbo shape of drill bits diameter 32mm-127mm provide smooth and fast drilling for kinds of concrete.
Applications: Kinds of granite or hard stone.
Welding Type: Silver or Laser welding.
Wet or Dry Use.
Under same bond conditions, the drilling speed of this type segments is much faster than normal flat segments, and all time the drilling speed is same.
The following are the normal Specifications we are selling:
Code No.
Diameter
Segment Size
Segment No.
BW-DS-DB-S04 Turbo Shape
1.25"(32mm)
16x3.0x10
4
1.38"(35mm)
16x3.0x10
4
1.50"(38mm)
16x3.0x10
5
1.63"(42mm)
16x3.0x10
5
1.75"(45mm)
16x3.0x10
6
1.88"(48mm)
16x3.0x10
6
2"(52mm)
16x3.0x10
7
2.25"(57mm)
24x3.5x11
5
2.50"(63mm)
24x3.5x11
6
2.75"(70mm)
24x3.5x11
7
3"(76mm)
24x3.5x11
8
3.25"(82mm)
24x3.5x11
9
3.50"(89mm)
24x3.5x11
10
4"(102mm)
24x3.5x11
10
4.25"(108mm)
24x3.5x11
11
4.50"(114mm)
24x3.5x11
11
4.75"(120mm)
24x3.5x11
11
5"(127mm)
24x3.5x11
11
The above specification & photos is only for Reference, other specification or design can be ordered by customers. we can manufacture products upon clients' needs.
