Diamond saw blade for glass magnesium board

Product parameters
Name: Diamond saw blade for glass magnesium board
Model Number: BW-DSB-GMB
Diameter 350-2000mm
Inner hole 50-100mm
Segment size 22*5.7*13 to 40*3.2*9
Segment number 26 to 128
Matrix thickness 2.3 to 6.5mm
Machine Hand held cutting machine
Advantage Good balance and high efficiency

Product Description


Diamond saw blade for glass magnesium board

This high quality diamond saw blade for glass magnesium board is suitable for hand-held cutting

machine or other cutting machine,this saw blade professional cutting glass

magnesium board,due to the diamond cutting blade for small and medium size,so it so easy to

use,the blade is smooth cutting and no distortion.



The following are the normal Specifications we are selling:

Name  Diameter Inner
Hole
Segment
Size
Segment
 Number
Matrix
 Thickness
Medium
cutting
blade
350mm 50mm 40*3.2*9 26 2.3mm
400mm 50mm 40*3.4*9 28 2.8mm
450mm 50mm 40*3.6*9 32 2.8/3.0mm
500mm 50mm 40*4.0*9 36 3.2mm
600mm 50mm 40*4.5*9 42 3.6mm
700mm 50mm 40*5.2*9 42 4.0/4.2mm
800mm 50mm 40*5.7*9 46 4.2mm
Medium
and
large
 cutting
 blade
900mm 100mm 22*5.7*13 88/64 4.5mm
1000mm 80/100/120 22*7.0*13 70 5.5mm
1100mm 100mm 22*7.0*13 74 5.5mm
1200mm 100mm 22*7.3*13 92 6.0mm
1300mm 100mm 22*7.3*13 88/96 6.0mm
1400mm 100mm 22*8.0*13 92 6.5mm
1500mm 100mm 22*7.0*13 96 5.5mm
1600mm 100mm 22*7.0*13 108 5.5mm
1700mm 100mm 22*7.0*13 120 5.5mm
1800mm 100mm 22*8.0*13 120 6.5mm
1900mm 100mm 22*8.0*13 128         5.5mm

Fast & Easy cutting, long life, very less or no chis, perfect performance.

The above specification & photos is only for Reference.

Other specification or design can be ordered by customers.

we can manufacture products upon clients' needs.



Safety First !



Kindly Noted:
When place order for glass magnesium board please inform the following:
  Diameter (Inch or mm)
  Inner Hole Size (Inch or mm)
  Installation hole (If, need drawing)
  Segment No. (how many pcs segment per blade)
  Segment Size (L x W x H, if possible please inform Steel Core Thickness)
  Use of saw blade (For glass?)
  Quantity NO. (How many pcs, or how many sets segments)
  Machine Powder/RPM (If possible)
  Feed Speed (M/Minute)
  Expected Cutting Depth (how many mm per time, forward or backward)
  Coolant System (Water or Oil, how many liters/Minute, etc.)
  Expected Shipping Date
  Special Requirements (If)

If only order glass magnesium board diamond segments please inform the following:
  Diameter (Inch or mm)
  Segment No. (how many pcs segment per blade)
  Segment Size (L x W x H, if better to inform the Steel Core Thickness)
  Use of saw blade (For glass?)
  Quantity NO. (how many sets segments)
  Machine Powder/RPM, Feed Speed, Normal Cutting Depth (If possible)
  Expected Shipping Date
  Special Requirements (If)
