Diamond circular saw blade for concrete with turbo segment

Product parameters
Name: Diamond circular saw blade for concrete with turbo segment
Model Number: BW-SBC-02
Diameter: From 105mm to 600 mm
Segment Length: 40mm
Segment Heigth: 10mm
Segement shape: Turbo segments
Machine: Concrete cutting machine
Usage: For cutting hard non-metallic materials
Performance: Highly stable
Welding Method: Laser welded
Cutting result: Flat surface and even size

Product Description


Diamond circular saw blade for concrete with turbo segment -Laser Welded


Laser Welded diamond saw blade with turbo segments  for concrete is designed for cutting hard non-metallic  materials, such as concrete, cured  concrete, concrete slabs and pipes, etc.

It is also for cutting reinforced concrete such as Road, Bridge, etc.


The following are the normal Specifications we are selling:



Code No.


Diameter
(mm/inch)
Segment Size
(mm)
Segment No.
(pcs/set)
Welding Method
BW-SBC-02-01
105mm(4")
40x2.2x10
8
Laser Welded
BW-SBC-02-02
115mm(4.5")
40x2.2x10
9
BW-SBC-02-03
125mm(5")
40x2.2x10
10
BW-SBC-02-04
150mm(6)
40x2.2x10
12
BW-SBC-02-05
180mm(7)
40x2.4x10
14
BW-SBC-02-06
200mm(8")
40x2.8x10
16
BW-SBC-02-07
230mm(9")
40x2.8x10
16
BW-SBC-02-08
250mm(10")
40x3.0x10
17
BW-SBC-02-09
300mm(12")
40x3.0x10
21
BW-SBC-02-10
350mm(14")
40x3.2x10
24
BW-SBC-02-11
400mm(16")
40x3.6x10
28
BW-SBC-02-12
450mm(18")
40x4.0x10
32
BW-SBC-02-13
500mm(20")
40x4.2x10
36
BW-SBC-02-14
600mm(24")
40x4.6x10
42



The above specification & photos is only for Reference, other specification or design can be ordered by customers.





Kindly Noted



When place order for diamond concrete saw blades please inform the following if possible:

Saw Blade Code No.
Diameter (Inch or mm)
Inner Hole Size (Inch or mm)
Installation hole (If, Need Customer's Drawing)
Silent or None Silent Saw Blade Please indicate
Segment No. (how many pcs segment per blade)
Segment Size (L x W x H, if possible please inform Steel Core Thickness)
Use of saw blade (For Marble, Limestone or other material)
Quantity NO. (How many pcs blades your would like to order)
Machine Powder/RPM (If possible)
Expected Shipping Date
Special Requirements (If)
