Diamond Segments of Gang Saw Blades for Marble Block Cutting & Squaring

Product parameters
Name: Diamond Segments of Gang Saw Blades for Marble Block Cutting & Squaring
Model Number: BW-DSGMB-00
Type Wet Use only
Segment Height 8mm,10mm,12mm
Segment Width 3.5mm to 5.5mm
Segment Length 20mm,24mm
Steel Core Thickness 2.5mm to 3.5mm
Usage Marble Block Cutting & Squaring
Machine Gang saw machine,marble block dressing machine
Welding Method Silver Welded
Performance Hightly stable
Advatage Good sharpness and Long lifespan
Cutting result Flat surface and even size

Product Description


Diamond Segments of Gang Saw Blades for Marble Block Cutting & Squaring



For the precision cutting of natural stones, the gang saw blades of variable dimensions and capacities are serving all types of marbles and other material plants (except granite) for well shaped blocks.



Usually there are 60-80pcs blades of one gang saw machine, also the segments is used for one-blade marble block dressing machine.



Wet use only, Fast & Easy cutting, long life, perfect performance.



The following are the normal specifications we are selling :



Segment Specification (mm)

Steel Core Thickness

Purpose

Blades No. per Machine

Length

Width

Height

20

3.5/4.0/4.5/5.0

8/10/12

2.5/3.0/3.5mm

Gangsaw Cutting

60-80pcs

24

4.5/5.0/5.5

10/12

3.0/3.5mm

Block Dressing

1pc



One-Blade Dressing GangSaw Blade GangSaw Segments



Recommended Parameters

Slow Moving High Speed Moving

Length of Stroke, mm

360

400

500

600

500

540

700

750

800

Strokes/min

80

80

80

80

120

120

120

120

120

Blade velocity, m/s

0.96

1.07

1.33

1.60

2.00

2.16

2.45

2.63

2.93

General Specifications



Required powder per blade

20-30 segments per blade

1.0-1.5kw

1.5-2.2kw

30-45 segments per blade

1.5-2.0kw

2.0-2.8kw

Down feed (cm/h)

Marble

10-20

15-35

Limestone

12-25

20-30

Agglomerate

10-20

25-35

Amount of cooling water per blade l/min

7-8

9-10

Deflection

Soft stone, mm

1.5-3.5

1.8-4.0

Hard stone, mm

1.5-3.5

1.8-4.0

Tension, kN (t)

80-90(8-9)

90-100(9-10)



The above specification & technical information is only for Reference, other or special specification can be ordered by customers.
