Diamond Segments of Drill Bits - Cuspate Top Turbo Shape
Diamond Segments Cuspate Top Turbo shape of drill bits diameter 32mm-356mm provide smooth and fast drilling.
Applications: Cured reinforced concrete with hard to soft aggregates, green concrete or abrasive material.
Welding Type: Silver welding.
Wet Use.
Compared to normal turbo segments, there is a cuspate top on the segments, with this structure initially the drilling speed is very fast.
The following are the normal Specifications we are selling:
Code No.
Diameter
Segment Size
Segment No.
BW-DS-DB-C06-01
2.25"(57mm)
24x3.5x14
5
BW-DS-DB-C06-02
2.50"(63mm)
24x3.5x14
6
BW-DS-DB-C06-03
2.75"(70mm)
24x3.5x14
7
BW-DS-DB-C06-04
3"(76mm)
24x3.5x14
8
BW-DS-DB-C06-05
3.25"(82mm)
24x3.5x14
9
BW-DS-DB-C06-06
3.50"(89mm)
24x3.5x14
10
BW-DS-DB-C06-07
4"(102mm)
24x3.5x14
10
BW-DS-DB-C06-08
4.25"(108mm)
24x3.5x14
11
BW-DS-DB-C06-09
4.50"(114mm)
24x3.5x14
11
BW-DS-DB-C06-10
4.75"(120mm)
24x4.0x14
11
BW-DS-DB-C06-11
5"(127mm)
24x4.0x14
11
BW-DS-DB-C06-12
5.5"(140mm)
24x4.0x14
12
BW-DS-DB-C06-13
5.75"(146mm)
24x4.0x14
13
BW-DS-DB-C06-14
6"(152mm)
24x4.0x14
13
BW-DS-DB-C06-15
6.25"(159mm)
24x4.0x14
14
BW-DS-DB-C06-16
6.5"(165mm)
24x4.0x14
15
BW-DS-DB-C06-17
7"(178mm)
24x4.0x14
16
BW-DS-DB-C06-18
8"(203mm)
24x4.5x14
18
BW-DS-DB-C06-19
9"(229mm)
24x4.5x14
20
BW-DS-DB-C06-20
10"(254mm)
24x4.5x14
23
BW-DS-DB-C06-21
11"(280mm)
24x5.0x14
25
BW-DS-DB-C06-22
12"(305mm)
24x5.0x14
27
BW-DS-DB-C06-23
13"(330mm)
24x5.5x14
30
BW-DS-DB-C06-24
14"(356mm)
24x5.5x14
32
The above specification & photos is only for Reference, other specification or design can be ordered by customers.
We can manufacture products upon clients' needs.
