Diamond Chamfering Wheels for Ceramic

Add / Delete to Basket

Product parameters

Name:	Diamond Chamfering Wheels for Ceramic
Model Number:	BW-DCFW-02
Diameter:	From 130mm to 300mm
Bond Type:	Metal Bond
Type：	Dry
Segment Width:	8mm,10mm,12mm,14mm
Segment Height:	10mm,12mm,14mm
Application:	Chamfering Ceramic Tiles after squaring

Product Description

Diamond Chamfering Wheels for Ceramic

The advantage of these produces is to make chamfering without water on ceramic tiles edges, which can achieve the same effect as traditional wet squaring and chamfering way. By the traditional wet mode, the tiles body will absorb water and some water will be still remained after drying, so ceramic tiles may become mildew and dyed when storing and transportation.

But by dry chamfering mode, can prevent effectively above mentioned quality problems, more over the drying equipments and process become unnecessary, so the power consumption can be lowered, labor cost, drying equipments and elated field can be saved. These products are suitable for make dry squaring and chamfering on glaze wall tiles. Our dry squaring and chamfering wheels are approved for their high grinding and cutting efficiency, excellent effect and stabile performance.

Metal Bond Diamond Chamfering Wheels for chamfering Ceramic Tiles after squaring to keep safety during storing, transportation, tiling and using.

The following are the normal Specifications we are selling:

Diameter (mm)	Segment Width (mm)	Segment Height (mm)	Fastening
130	8/10/12	10/12/14	Depending On The Machine
150	8/10/12	10/12/14
170	8/10/12	10/12/14
200	8/10/12	10/12/14
220	8/10/12	10/12/14
250	8/10/12/14	10/12/14
300	8/10/12/14	10/12/14

The above specification is only for Reference, other or special specification can be ordered by customers.
