Cuspate Top Segmented Diamond Core Drill Bits for Concrete

Product parameters
Name: Cuspate Top Segmented Diamond Core Drill Bits for Concrete
Model Number: BW-DDB-C02-03
Diameter: From 57mm to 356mm
Segment Width: 3.5mm,4.0mm,5.0mm,5.5mm
Segment Height: 14mm
Drilling Type: Wet use
Welding Type: Silver welding
Use: Smooth drilling and avoid segments loosing.
Machine: Hydraulic drilling machines, electric hand-held drillers.
Industry: Diamond tools
Application: Cured reinforced concrete with hard to soft aggregates, green concrete or abrasive material.
Drilling result: Flat surface and even size
Performance: Hightly stable

Product Description


Diamond Drill Bits for Concrete - Wet Use - Cuspate Top Segmented


Cuspate Top Segmented diamond core drill bits diameter 57mm-356mm provide smooth and fast drilling.

Applications: Cured reinforced concrete with hard to soft aggregates, green concrete or abrasive material.

Welding Type: Silver welding.

Wet Use.

The following are the normal Specifications we are selling


Code No. Diameter Segment Size Segment No.
BW-DDB-C02-03
Cuspate Top Segmented
2.25"(57mm) 24x3.5x14 5
2.50"(63mm) 24x3.5x14 6
2.75"(70mm) 24x3.5x14 7
3"(76mm) 24x3.5x14 8
3.25"(82mm) 24x3.5x14 9
3.50"(89mm) 24x3.5x14 10
4"(102mm) 24x3.5x14 10
4.25"(108mm) 24x3.5x14 11
4.50"(114mm) 24x3.5x14 11
4.75"(120mm) 24x4.0x14 11
5"(127mm) 24x4.0x14 11
5.5"(140mm) 24x4.0x14 12
5.75"(146mm) 24x4.0x14 13
6"(152mm) 24x4.0x14 13
6.25"(159mm) 24x4.0x14 14
6.5"(165mm) 24x4.0x14 15
7"(178mm) 24x4.0x14 16
8"(203mm) 24x4.5x14 18
9"(229mm) 24x4.5x14 20
10"(254mm) 24x4.5x14 23
11"(280mm) 24x5.0x14 25
12"(305mm) 24x5.0x14 27
13"(330mm) 24x5.5x14 30
14"(356mm) 24x5.5x14 32



The above specification is only for Reference, other or special specification can be ordered by customers.







Kindly Noted



When place order for Diamond Core Drilling Bits please inform:

Code No. of Diamond Core Drill Bits
Diameter (Inch or mm)

Drill Bit Length
Segment Height & Width
Material Driling: For Granite, or marble, or other material?
Order Quantity & Expected Shipping Date
Special Requirements (If).
