Crown Shape Diamond Segments of Drill Bits

Product parameters
Name: Crown Shape Diamond Segments of Drill Bits
Model Number: BW-DS-DB-C01
Type: Wet Use
Diameter: 14mm to 52mm
Segment Width: 2.5mm,3.0mm
Segment Height: 10mm
Segment shape: crown shaped
Applications: Cured reinforced concrete with hard to soft aggregates, green concrete or abrasive material.
Machine: Drilling tools
Industry: Diamond tools
Welding method: Silver welding
Drilling result: Flat surface and even size
Advatage: Good sharpness and Long lifespan

Product Description


Diamond Segments of Drill Bits - Crown Shape



Diamond segments of small diameter drill bits with crown of 22mm-52mm provide smooth drilling and avoid segments loosing. High Concentration of diamond offers long drilling life.



Applications: Cured reinforced concrete with hard to soft aggregates, green concrete or abrasive material.



Welding Type: Silver welding.  Wet Use.



The following are the normal Specifications we are selling:



Code No. Diameter Segment Width Segment Height
BW-DS-DB-C01-01 14mm 2.5mm 10mm
BW-DS-DB-C01-02 16mm (5/8”) 2.5mm 10mm
BW-DS-DB-C01-03 18mm 2.5mm 10mm
BW-DS-DB-C01-04 3/4"(20mm) 2.5mm 10mm
BW-DS-DB-C01-05 7/8"(22mm) 2.5mm 10mm
BW-DS-DB-C01-06 1"(25mm) 2.5mm 10mm
BW-DS-DB-C01-07 1.18"(29mm) 2.5mm 10mm
BW-DS-DB-C01-08 1-1/4"(32mm) 2.5mm 10mm
BW-DS-DB-C01-09 1-3/8"(35mm) 2.5mm 10mm
BW-DS-DB-C01-10 1-1/2"(38mm) 3.0mm 10mm
BW-DS-DB-C01-11 1.63"(42mm) 3.0mm 10mm
BW-DS-DB-C01-12 1-3/4"(45mm) 3.0mm 10mm
BW-DS-DB-C01-13 1.88"(48mm) 3.0mm 10mm
BW-DS-DB-C01-14 2"(52mm) 3.0mm 10mm



The above specification & photos is only for Reference, other specification or design can be ordered by customers.



We can manufacture products upon clients' needs.
