Crown Segmented Diamond Core Bits for Concrete

Product parameters
Name: Crown Segmented Diamond Core Bits for Concrete
Model Number: BW-DDB-C02-01
Diameter: From 22mm to 52mm
Segment Width: 2.5mm,3.0mm
Segment Height: 10mm
Drilling Type: Wet use
Welding Type: Silver welding
Use: Smooth drilling and avoid segments loosing.
Machine: Hydraulic drilling machines, electric hand-held drillers.
Industry: Diamond tools
Application: Cured reinforced concrete with hard to soft aggregates, green concrete or abrasive material.
Drilling result: Flat surface and even size
Performance: Hightly stable

Product Description


Diamond Drill Bits for Concrete - Wet Use - Crown Segmented



Crown Segmented Diamond Core Bits 22mm-52mm provide smooth drilling and avoid segments loosing. High Concentration of diamond offers long drilling life.



Used on Hydraulic drilling machines, electric hand-held drillers.



Applications: Cured reinforced concrete with hard to soft aggregates, green concrete or abrasive material.



Welding Type: Silver welding.Wet Use.





The following are the normal Specifications we are selling:



Code No. Diameter Segment
Width
Segment
 Height
BW-DDB-C02-01
Crown Segmented
7/8"(22mm) 2.5mm 10mm
1"(25mm) 2.5mm 10mm
1.18"(29mm) 2.5mm 10mm
1-1/4"(32mm) 2.5mm 10mm
1-3/8"(35mm) 2.5mm 10mm
1-1/2"(38mm) 3.0mm 10mm
1.63"(42mm) 3.0mm 10mm
1-3/4"(45mm) 3.0mm 10mm
1.88"(48mm) 3.0mm 10mm
2"(52mm) 3.0mm 10mm



The above specification is only for Reference, other or special specification can be ordered by customers.



Kindly Noted:



When place order for Diamond Core Drilling Bits please inform:

Code No. of Diamond Core Drill Bits
Diameter (Inch or mm)

Drill Bit Length
Segment Height & Width
Material Driling: For Granite, or marble, or other material?
Order Quantity & Expected Shipping Date
Special Requirements (If)
