Your position: Home > Products > Machinery and Other Tools > Calcium Silicate Board Tools > Continuous saw blade for calcium silicate board
| Product parameters |
| Name: | Continuous saw blade for calcium silicate board |
| Model Number: | BW-DSB-CSB |
| Diameter | 300-550 |
| Segment length | 40 |
| Segment thickness | 2.8/3.0-4.6/4.8 |
| Segment height | 8/10/12/15/20 |
| Segment number | 21-40 |
| Application | For calcium silicate board |
| Machine | Stone cutting machine,table cutting machine |
| Advantage | Stabe cutting and high efficiency |  |
Continuous saw blade for calcium silicate board
This high quality diamond saw blade for calcium silicate board is suitable for hand-held cutting
machine or other cutting machine,this saw blade professional cutting calcium
silicate board,due to the diamond cutting blade for small and medium size,so it so easy to use,
the blade is smooth cutting and no distortion.
Continuous saw blade for calcium silicate board
The following are the normal specifications we are selling:
| Diameter | Segment length | Segment thickness | Segment height | Segment number |
| 300 | 40 | 2.8/3.0 | 8/10/12/15/20 | 21 |
| 350 | 40 | 3.0/3.2 | 8/10/12/15/20 | 24 |
| 400 | 40 | 3.4/3.6 | 8/10/12/15/20 | 28 |
| 450 | 40 | 3.8/4.2 | 8/10/12/15/20 | 32 |
| 500 | 40 | 4.0/4.2 | 8/10/12/15/20 | 36 |
| 550 | 40 | 4.6/4.8 | 8/10/12/15/20 | 40 |
The above specification & photos is only for Reference.
Other specification or design can be ordered by customers.
When place order for calcium silicate board cutting tools please inform the following:
Diameter (Inch or mm)
Inner Hole Size (Inch or mm)
Installation hole (If, need drawing)
Segment No. (how many pcs segment per blade)
Segment Size (L x W x H, if possible please inform Steel Core Thickness)
Use of saw blade (For glass?)
Quantity NO. (How many pcs, or how many sets segments)
Machine Powder/RPM (If possible)
Feed Speed (M/Minute)
Expected Cutting Depth (how many mm per time, forward or backward)
Coolant System (Water or Oil, how many liters/Minute, etc.)
Expected Shipping Date
Special Requirements (If)
If only order calcium silicate board cutting tools segments please inform the following:
Diameter (Inch or mm)
Segment No. (how many pcs segment per blade)
Segment Size (L x W x H, if better to inform the Steel Core Thickness)
Use of saw blade (For glass?)
Quantity NO. (how many sets segments)
Machine Powder/RPM, Feed Speed, Normal Cutting Depth (If possible)
Expected Shipping Date
Special Requirements (If)
Safety first!!!
