Cold press machine for diamond segment

Product parameters
Name: Cold press machine for diamond segment
Model Number: BWM-HP50-L
Power 7.5 KW
Rated Current 15 A
Finished error ±0.1 g
Efficiency 6 times / Min (3 layers)
Pressing layers 1-9 Layers
Dimensions 1450mm × 850mm × 1750mm
Rated voltage 380V, 50Hz
Working Pressure 50 Ton
Packing depth 1-40 mm
Weight 1.3 Ton

Product Description


Cold press machine for diamond segment

The BWM-HP50-L cold pressed machine is designed for pressing and processing multi-layers

diamond segments,such as sandwich diamond segments. The control system uses new

industrial PLC man-machine interface technology,reliable,intuitive and easy to understand.

It’s max pressure can up to 50 ton.



Cold press machine for diamond segment

The followings are the normal specifications of our cold press machine for diamond segment:

Parameters
Numerical
Type
BW-HP50-L
Power
7.5 KW
Rated Current
15 A
Finished error
±0.1 g
Efficiency
6 times / Min (3 layers)
Pressing layers
1-9 Layers
Dimensions
1450mm × 850mm × 1750mm
Rated voltage
380V, 50Hz
Working Pressure
50 Ton
Packing depth
1-40 mm
Weight
1.3 Ton
The following are some specifications of our cold press machine for diamond segment.

We can also produce by client’s request.





Kindly noted:

When order cold pressed machine please Confirm.
Code No. of cold pressed machine ( BWM-HP50-L)
Type(?)
Number(?)
