Asphalt & Green Concrete Cutting Diamond Saw Blades

Product parameters
Name: Asphalt & Green Concrete Cutting Diamond Saw Blades
Model Number: BW-SBA-03
Diameter: From 300mm to 600mm
Segment Length: 40mm
Segment Heigth: 10mm
Segement shape: With Drop Segment (Low Protection Teeth)
Machine: Flat saw machine, concrete cutting machine
Usage: For Asphalt, Green Concrete and Abrasives material Cutting
Performance: Highly stable
Welding Method: Laser welded
Cutting result: Flat surface and even size

Product Description


Asphalt & Green Concrete Cutting Diamond Saw Blades



TCT Inserted (Side Protection Teeth)



Laser welded Diamond Saw Blade with side protection teeth used for Asphalt, Green Concrete and Abrasives material cutting with high efficiency.



Side protection teeth prevent wear and tear of the steel core by abrasive materials.



Suitable for Flat saw machines with power more than 35HP.



The following are the normal Specifications we are selling:

Code No. Diameter (mm/inch) Segment Size (mm) Segment No. (pcs/set) Welding Method
BW-SBA-03-01 300mm(12") 40x3.0x10 21 Laser Welded
BW-SBA-03-02 350mm(14") 40x3.2x10 24
BW-SBA-03-03 400mm(16") 40x3.6x10 28
BW-SBA-03-04 450mm(18") 40x4.0x10 32
BW-SBA-03-05 500mm(20") 40x4.2x10 36
BW-SBA-03-06 600mm(24") 40x4.6x10 42

The above specification & photos is only for Reference, other specification or design can be ordered by customers.



Kindly Noted



When place order for Diamond Asphalt & Green Concrete Saw Blades please inform the following if possible:

Saw Blade Code No.
Diameter (Inch or mm)
Inner Hole Size (Inch or mm)
Installation hole (If, Need Customer's Drawing)
Silent or None Silent Saw Blade Please indicate
Segment No. (how many pcs segment per blade)
Segment Size (L x W x H, if possible please inform Steel Core Thickness)
Use of saw blade (For Marble, Limestone or other material)
Quantity NO. (How many pcs blades your would like to order)
Machine Powder/RPM (If possible)
Expected Shipping Date
Special Requirements (If)






Please use the following before operating the cutting:
