Product parameters |
900mm-2000mm Diamond Segments for Marble Cutting
Diamond Segment of 900-2000mm circular saw blades for Block Cutting of Marble, Limestone, Slate, kinds of Soft Stone without quartz.
Welding method: Silver Welding.
Wet use only.
The following are the normal Specifications we are selling:
Diameter (mm) |
Segment Dimension (L × W × H) |
Segment No. |
Structure | ||
Length |
Width (Box Type) |
Height |
|||
900 | 24 | 6.5 | 8/10/12 | 64 |
Sandwich (only) |
1000 | 24 | 7.0 | 8/10/12 | 70 | |
1200 | 24 | 7.5 | 8/10/12 | 80 | |
1300 | 24 | 8.0 | 8/10/12 | 88 | |
1350 | 24 | 8.0 | 8/10/12 | 88 | |
1400 | 24 | 8.5 | 8/10/12 | 96 | |
1600 | 24 | 9.0 | 8/10/12 | 104/108 | |
1800 | 24 | 9.5 | 10/12 | 120 | |
2000 | 24 | 10.5 | 10/12 | 128 |
The above specification & photos is only for Reference, other specification or design can be ordered by customers.
Kindly Noted :
Please use high frequency Silver Welded machine instead of Fire to make the brazing, the welding time is only a few seconds, otherwise the diamond inside the segments will probably be damaged by the high temperature, then the cutting performance will be Reduced!
