8mm stone cutting drill bit

Add / Delete to Basket

Product parameters

Name:	8mm stone cutting drill bit
Model Number:	BW-DDB-S01-02
Product name	Stone cutting drill bit
Diameter	8mm
Pipe length	100mm
Connection	12B
Application	For granite,marble and many other stone
Use	Dry and wet use
Machine	Diamond drill electric hand-held or CNC drilling machine
Advantage	Good stable and long lifespan

Product Description

Stone cutting drill bit

8mm stone cutting drill bits are suitable for small diameter diamond drill electric hand-held or on a

CNC drilling machine, suitable for all kinds of stone, such as the drilling of granite, marble,

sandstone, limestone, slate,and other small caliber.

Specially for small-diameter hole drilling.It can be dry or wet use.

Stone cutting drill bit

The following is the normal size of our stone cutting drill bit:

Code No.	Diameter	Segment Size	Use	Pipe Length	Welding Method	Adaptor
BW-DDB-S01-01	6mm (1/4”)	D6xH11	Wet or Dry	4" (100mm)	Silver Welding	5/8"-11 M14 1/2 Gas 10mm
BW-DDB-S01-02	8mm (5/16”)	D8xH11
BW-DDB-S01-03	10mm (3/8”)	D10xH11
BW-DDB-S01-04	12mm	D12xH11
BW-DDB-S01-05	13mm (1/2”)	D13xH11
BW-DDB-S01-06	14mm	D14xH11
BW-DDB-S01-07	16mm (5/8”)	D16xH11
BW-DDB-S01-08	18mm	D18xH11

The above specifications are for reference only.Other specifications can be ordered by customers.

When order stone cutting drill bit please Confirm.

Code No. of stone cutting drill bit(BW-DDB-S01-02)
Diameter(?)

Segment length(?)

Thread(?)

Quantity(?)
