60 ton intelligent hydraulic pressed machine

Product parameters
Name: 60 ton intelligent hydraulic pressed machine
Model Number: BWM-HP60
Total power 7.5 KW
Voltage 380 V
Working current 18 A
Control system voltage 24 V
Pressure control range 0 - 60Ton
Oil tank volume 230 L
Control system Industry PLC and touch screen
Volume of machine 760mm * 1600mm * 2300mm ( L*W*H )
Weight 1400 Kg
Error range ±0.02 g/pc
Production quantity 1200 times/h

Product Description


60 ton intelligent hydraulic pressed machine

The BWM-HP60 intelligent hydraulic pressed machine is designed for processing the press

pieces of diamond segments. The control system uses new industrial PLC man-machine interface

technology,reliable,intuitive and easy to understand.It’s max pressure can up to 100 ton.



60 ton intelligent hydraulic pressed machine
The followings are the normal specifications of our 60 ton intelligent hydraulic pressed machine:
 Parameters
 Numerical
 Type
 BW-HP-60
 Total power
 7.5 KW
 Voltage
 380 V
 Working current
 18 A
 Control system voltage
 24 V
 Pressure control range
 0 - 60Ton
 Oil tank volume
 230 L
 Pressure range
 Min weight 0.5g  ( Including diamond powder )
 Min weight 0.4g  ( Not including diamond powder )
 Max weight 30g  ( Following with mould )
 Control system
 Industry PLC and touch screen
 Volume of machine
 760mm * 1600mm * 2300mm  ( L*W*H )
 Weight
 1400 Kg
 Error range
 ±0.02 g/pc
 Production quantity
 1200 times/h
The following are some specifications of our polishing machine.
We can also produce by client’s request.


 Kindly noted:

When order 60 ton intelligent hydraulic pressed machine please Confirm.
Code No. of 60 ton intelligent hydraulic pressed machine ( BWM-HP60)
Type(?)
Number(?)
