48inch 1200mm Diamond Cutting Segment For Single Blade

Add / Delete to Basket

Product parameters

Name:	48inch 1200mm Diamond Cutting Segment For Single Blade
Model Number:	BW-DSGB-7-15
Segment Length	24mm
Segment Thickness	7.6/7mm
Segment Height	15/10mm
Brand Name	Boreway
Segment Shape	M Shape
Process Type	Hot Press
Use	Wet Use For Cutting Granite Stone Block
Machine	Bridge Cutting Machine And Single Arm Machine

Product Description

48inch 1200mm Diamond Cutting Segment For Single Blade

Description:

24x7.6//7x15/10mm diamond segment for single blade.Our saw blade segment can be used for cutting granite, marble, basalt, volcanic, lava stone, andesite, travertine, limestone, sandstone, quartz, artificial stone, microcrystal stone.

In the manufacturing process, the metal powder and diamond grit mixture is hot pressed at high temperatures to form a solid metal alloy (called the bond or matrix) in which the diamond grit is retained.

M shape diamond cutting segment is slightly wider than the blade core. This allows the cutting edge to penetrate through the material while protecting the steel body.

Advantage:

1.Stone cutting segment wholesales,cut granite hard stone and cut it with bridge cutting machine.

2.Multi saw blade segment for granite.high percent of cobalts.Precise segment size.High grade of diamonds.

3. M type diamond cutting segment.this diamond granite segment are ensure block with average thickness,low noise with smooth cutting,save energy on powder and stone.

Specification:

The following specifications of diamond segment for single blade:

Blade Diameter	Segment Length	Segment Thickness	Segment Height	Production Method
1200mm （48 Inch）	24mm	7.6/7.0mm	15/10mm	Sintered

In addition, the speed of the combined saw blade is required to be 280-320 rpm, and the trolley can not be transported too fast!

Other specifications of cutter segment:

diamond tips cutting segments for marble

PS:A certain amount of cooling water should be added when cutting the cutter head, and the spray water flow should be large, so that it has a better cooling effect!

Multi-blade and single-disc saw blade specifications:

Product Details:

48inch 1200mm Diamond Cutting Segment For Single Blade

48inch 1200mm Diamond Cutting Segment For Single Blade 99

Application:

M shape diamond segments wet use for bridge cutting machine and single arm machine.

Diamond segment for single blade and mutil saw, for cutting Marble,Granite, Sandstone, various stone block.

Cutting effect:

Application machine:

Diamond tips cutting segments for marble suitable for bridge cutting machines, manual handling cutting machines or table cutting machines.

diamond tips cutting segments for marble silver welding by high frequency welding machine.

Saw Blade Segment is wet use

High frequency silver welded machine is recommended instead of welding by fire.

Don’t weld diamond segment for a long time, just a few minutes, otherwise the diamond inside might be damaged because of the high temperature, which will affect the cutting performance of the granite segment greatly.

Relatsd Products:

Multi Blade Diamond Segment	W Shape Edge Cutting Diamond Segment for Granite	1400mm Diamond Cutting Tools Marble Block Diamond Segments

About us:

Our serice:

1. Low order quantity: It can meet the test order you need.

2. Fast delivery: We get great discounts from freight forwarders.

3. OEM Acceptable: We can produce according to your samples or drawings.

4. Good quality: We have a strict quality control system. Has a good reputation in the market.

5. Good service: We regard our customers as God with a high degree of professionalism and enthusiasm.

FAQ:

1. If we want to order your product, how do we know your quality?

Please test in a very small order and then you will know the quality. Now, so
Many people in the world use Chinese products because of their high quality and high quality.
competitive price. We are a professional diamond tool manufacturer.
In any case, for more than 8 years, confirm the quality of our products, small test orders will be tested
necessary.

2.Can you provide samples for free?
We do not provide free samples. Based on years of experience, we believe that people will get them.
By paying for samples, we will cherish and appreciate the more they get. We would have been
Be prepared to offer our potential customers a special discount for participating in the test.
It is very important to provide feedback to us and we will be very grateful.

3. Does your company accept customization?
Of course, we accept it. Includes different colors, gravel, etc. We can also tag your own logo
And the brand on the board. You want us to produce any new products for you, just send us your products.
Drawing or sample, we produce the same. We will not sell such products to others
Only customers can get a license.

Plese note:

1. Please provide items before purchase.

2. Please provide the model number before purchase.

3. Other specifications can be customized according to requirements.
