2200mm welding machine for diamond saw blade

Product parameters
Name: 2200mm welding machine for diamond saw blade
Model Number: BWM-HJ2200
Type BWM-HJ2200
Welding range Ø350-ø2200 mm
Dimension 650mm*700mm*1900mm
Verticality ≤±0.03 mm
Runout ≤±0.03 mm
Water pressure ≥0.2 MPa
Power 400 W
Weight 200 KG
Welding speed 3-9 Sed / Pc
Air pressure 0.8 MPa
Water Consumption 2 M³

Product Description


2200mm welding frame machine for diamond saw blade

The “BWM-HJ2200” welding frame can weld diamond saw blade from ø350mm to ø2200mm.




2200mm welding frame machine for diamond saw blade
The “BWM-HJ2200” welding frame can weld diamond saw blade from ø350mm to ø2200mm.
The followings are the normal specifications of our 2200mm saw blade welding machine frame.

Parameters
Numerical
Type
BW-HJ2200
Welding range
Ø350-ø2200 mm
Dimension
650mm*700mm*1900mm
Verticality
≤±0.03 mm
Runout
≤±0.03 mm
Water pressure
≥0.2 MPa
Power
400 W
Weight
200 KG
Welding speed
3-9 Sed / Pc
Air pressure
0.8 MPa
Water Consumption
2 M³

The above specifications are for reference.
Other or special specifications can be ordered by customers.
Note:
This machine doesn’t include high frequency Welding machine , air compressor and water pump.

Kindly noted:
When order 2200mm welding frame machine please Confirm.
Code No. of 2200mm welding frame machine BWM-HJ2200)
Type(?)
Number(?)
