100 ton intelligent hydraulic pressed machine

Add / Delete to Basket

Product parameters

Name:	100 ton intelligent hydraulic pressed machine
Model Number:	BWM-HP-100
Total power	7.5 KW
Voltage	380 V
Working current	18 A
Control system voltage	24 V
Pressure control range	0 - 100Ton
Oil tank volume	230 L
Control system	Industry PLC and touch screen
Volume of machine	760mm * 1600mm * 2300mm ( LWH )
Weight	1800 Kg
Error range	±0.02 g/pc
Production quantity	1200 times/h

100 ton intelligent hydraulic pressed machine

The BW-HP100 intelligent hydraulic pressed machine is designed for processing the press

pieces of diamond segments.

The control system uses new industrial PLC man-machine interface technology,reliable,intuitive

and easy to understand.It’s max pressure can up to 100 ton.

100 ton intelligent hydraulic pressed machine

The followings are the normal specifications of our 100 ton intelligent hydraulic pressed machine:

Parameters	Numerical
Type	BWM-HP-100
Total power	7.5 KW
Voltage	380 V
Working current	18 A
Control system voltage	24 V
Pressure control range	0 - 100Ton
Oil tank volume	230 L
Pressure range	Min weight 0.5g ( Including diamond powder )
	Min weight 0.4g ( Not including diamond powder )
	Max weight 50g ( Following with mould )
Control system	Industry PLC and touch screen
Volume of machine	760mm * 1600mm * 2300mm ( LWH )
Weight	1800 Kg
Error range	±0.02 g/pc
Production quantity	1200 times/h

The following are some specifications of our polishing machine

We can also produce by client’s request.

Kindly noted:

When order 100 ton intelligent hydraulic pressed machine please Confirm.

Code No. of 100 ton intelligent hydraulic pressed machine ( BWM-HP100)
Type(?)

Number(?)
